View Mini is a refined evolution of the original View fixture, designed to meet modern architectural and performance demands in a more compact form. With transparent vertical optics resized to harmonize even more seamlessly with architectural materials, View Mini embodies a further expression of minimalist design. Like its predecessor, it features Fluxwerx’s proprietary Anidolic optical extraction technology, delivering exceptional performance with a clean aesthetic. These optics appear as a floating fenestration that maintains transparency when lit or unlit, ensuring superior visual comfort with no visible LED point source, minimal glare, and wide row spacing up to 15 feet on center, providing 35 footcandles at just 0.4 W/ft².
Engineered for energy efficiency and optical precision, View Mini offers direct and indirect general area lighting distributions with independent control of uplight and downlight. This makes it ideal for multipurpose environments such as conference rooms, classrooms, and collaborative workspaces where different lighting conditions are required. The View Mini U|D version provides dimmable or switchable independent control of indirect and direct lighting, with a native distribution of 70% uplight and 30% downlight and a maximum delivered output of 4000 lumens.
The fixture is offered in standalone lengths of 4, 6, or 8 feet and can be specified in continuous run lengths in 2-foot increments. Three pre-installed endcap styles—Beam, Radius, and Square—enhance the visual integration with architectural surroundings. View Mini’s minimalist form factor is available in two heights: the standard 4.5" and the compact Mini version at 3.5", enabling designers to scale luminaires to fit various interior volumes while maintaining consistent design language.
View Mini comes with fully integrated and pre-tested drivers, junction boxes, and mounting components, enabling simple and quick installation. Designed to fit various ceiling types including grid, drywall, or hard lid, its agnostic driver design allows for easy integration with most lighting control and building energy management systems. Fixture joints require no electrical connections, enabling virtually seamless continuous runs.
Constructed from precision-machined, clear anodized architectural-grade extruded aluminum, View Mini includes factory-installed joints and endcaps for perfect alignment and finish. It’s available in standard finishes including clear anodized, white, black, and metallic silver powder coat, with white canopies provided standard. Aircraft cable suspension and stainless steel fasteners ensure secure installation.
View Mini’s optical system utilizes molded high-transmittance acrylic lenses combined with anidolic structures that extract and direct light with exceptional control. The luminaire is powered by a long-life mid-flux LED system, designed to maintain ≥L90 lumen output at 60,000 hours per TM21 standards. Available in color temperatures of 3000K, 3500K, or 4000K, it offers CRI options of ≥80 with R9≥0 or ≥90 with R9≥50, all bin-sorted within ≤2 SDCM for tight color consistency.
Electrically, View Mini is equipped with high-efficiency multi-volt drivers supporting 120–277V and optional transformers for 347V operation. The luminaire meets ANSI surge protection standards and features a power factor >0.90 and THD <20%. Dimming capabilities include standard 3%, with options down to 1% or 0.1%. An optional emergency battery pack delivers 10W Class 2 output for 90 minutes, typically producing 1150–1750 lumens depending on LED efficacy, while an optional GTD device ensures full output during emergency operation by bypassing dimming controls.
For remote power applications, recommended low-voltage wire gauges vary by distance: 18 AWG for up to 30 feet, 14 AWG for 50 feet, and 12 AWG for 80 feet. The fixture is suitable for dry or damp indoor environments (0–30°C ambient), but should not be used in spaces with aggressive chemicals or natatorium conditions like pools or saunas. Cleaning should only be done with a soft, water-damp cloth.
View Mini meets UL (U.S. and Canada) safety standards, is CCEA Chicago Plenum rated, and is Living Building Challenge (LBC) Declared, affirming its commitment to sustainable design. With its advanced technology, elegant proportions, and high performance, View Mini delivers a convergence of form and function for today’s design-forward spaces.
