The Mosaico L is a high-powered 300W LED image projector built for precision outdoor applications. Housed in a robust IP66-rated die-cast enclosure, it is specifically engineered for long-range architectural lighting, including textured, static, or animated façade projections. Capable of delivering a remarkable output of up to 11,700 lumens, it combines durability with high-performance optics and an extensive feature set, making it ideal for both temporary and permanent installations.
Equipped with a linear motorized zoom ranging from 7° to 49°, the Mosaico L offers outstanding versatility, whether it's being used for near-field accentuation or distant architectural illumination. The optical system includes a 110mm HD anti-reflection lens with achromatic coating and motorized focus for precise beam shaping. Inside, the 300W cold white LED engine with an 8,000K color temperature provides crisp, high-lumen projection with consistent output across its beam range.
To enhance the creative possibilities, the fixture includes a rotating animation wheel, seven interchangeable rotating gobos, and a motorized shutter system with four independently adjustable blades that allow precise beam framing. The framing system can also be rotated ±45°, enabling accurate masking within architectural shapes. Additionally, it features a linear frost filter for softening the beam and a 3-facet circular prism with indexing and bi-directional rotation for further effect enhancement.
The color system is built around a color wheel offering seven filter positions plus open, allowing a dynamic palette to complement the white LED source. The fixture supports advanced scene creation through its FX generator, which enables the recording and playback of chases and shows. Designed for intuitive and flexible control, the Mosaico L supports DMX512, RDM, and wireless protocols including CRMX and W-DMX, with multiple channel modes and an integrated graphic user interface for stand-alone operation and configuration. Firmware updates can be performed via DMX using external hardware.
Electronics are optimized for high-performance environments with flicker-free operation thanks to an adjustable PWM frequency range of 600 to 25,000 Hz. The dimming system offers a 0–100% linear curve with four selectable dimming profiles and an electronic strobe/shutter operating from 1–30 Hz. The onboard battery backup keeps display settings accessible even when the unit is not powered.
On the electrical side, the projector operates on a 100–240V AC supply at 50/60Hz, with a maximum power consumption of 440W. Up to six units can be powered on a single 230V line, and the system supports high-efficiency operation with a power factor above 0.98. Connectivity is handled via IP-rated molded connectors for signal and power, with a 1.8-meter lead, and both XLR and bare-end 16A adaptors are included.
Physically, the Mosaico L measures 362 x 428 x 451 mm and weighs 25 kg. The fixture features a hybrid cooling system combining heat pipe technology with a low-noise fan for reliable thermal management. Certified for CE, UKCA, RCM, cTUVus, and FCC compliance, the Mosaico L stands as a professional-grade solution for demanding architectural lighting applications that require long-term resilience, high output, and creative versatility.
