The CO product family combines modern circular design with the technical precision and versatility expected in contemporary urban lighting. Drawing from the design language of the CN series, CO luminaires incorporate square LED modules into a round luminaire head, achieving a sleek, balanced appearance while maintaining optimal lighting performance. Their clean, understated form adds aesthetic elegance to streets, sidewalks, and other public spaces, making them an ideal choice for urban environments where both design and function matter.
At the heart of the CO luminaire is its flexible and efficient lighting system. With the ability to incorporate up to five centrally mounted modules, each housing 16 high-performance LEDs, the fixture delivers focused illumination exactly where it’s needed. A wide range of light distributions allows precise control over beam direction and intensity, ensuring adaptability to various outdoor lighting scenarios. The luminaire is available in 500 mm and 600 mm diameters to accommodate different spatial requirements and design preferences.
Engineered for durability, the CO housing is crafted with aluminum featuring a low copper content (≤ 0.08%), with optional ewoECP corrosion protection available for harsher environments. Performance enhancements are also offered through ewoLightLayers, which include integrated RBL (backlight shield) and AGR (anti-glare protection) components, improving visual comfort and reducing light spill in sensitive areas.
The CO series supports two distinct configurations: the A–Series and the T–Series. The A–Series operates at a current feed ranging from 200 mA to 500 mA, delivering a maximum luminous flux of 14,700 lumens. It is compatible with DALI, 1–10 V interfaces, stand-alone programming, or Line Switch, depending on the project’s control requirements. Available color temperatures include 2,200 K, 2,700 K, 3,000 K, 4,000 K, and 5,700 K with CRI values ranging from ≥70 to ≥80, with higher CRI options available on request. Features such as constant lumen output (CLO) and AC/DC emergency power supply can also be integrated. Smart lighting control is supported through embedded modules or external Zhaga interfaces, offering seamless connectivity for intelligent lighting networks.
The T–Series, tailored for more specific needs, supports current feeds up to 225 mA and delivers up to 4,600 lumens. Tunable white technology allows a dynamic range from 2,200 K to 6,500 K with standard CRI ≥80 and optional CRI ≥90 for high fidelity color rendering. The DALI T8 interface ensures smooth dimming and control functionality.
Together with the A–Series’ vast optical customization potential—enabling over 1.7 billion lens combinations—and the advanced adaptability of systems like ewoLightTile and ewoLightLayers, the CO product family offers unmatched flexibility in light shaping. Whether wall- or pole-mounted, CO luminaires provide a smart, efficient, and visually appealing solution for today’s urban lighting challenges.
