The MAC Aura XIP is a high-performance moving head wash light that introduces a revolutionary aura filament effect and full pixel control, offering dynamic video mapping options on the beam, aura, or both. As the newest addition to the MAC Aura family, this fixture stands out as the first in its class to achieve an IP54 outdoor rating—delivering full weather protection without compromising weight, size, or aesthetics. Thanks to Martin’s intelligent outdoor-capable design, the MAC Aura XIP offers outstanding optical performance, including a beautifully even wash field with a soft edge, minimal stray light, and powerful mid-air beams with precise light engine control.
This fixture is engineered for versatility and is ideal for a wide spectrum of applications—from high-energy concert and touring productions to festivals and outdoor events. Its smart design also makes it quiet and compact enough for use in theater, television studios, and corporate settings. With a narrower beam, improved wash output, and the distinctive aura filament effect, lighting designers have a wide range of creative possibilities at their fingertips. Rental companies will value its sealed design, which helps reduce maintenance and supports use in diverse environments, from indoor stages to outdoor festivals.
Built for performance in all conditions, the MAC Aura XIP uses Martin’s smart outdoor-proofing technology to protect against rain, snow, sand, and ice, while maintaining a sleek, compact profile. This ensures it performs just as well indoors, eliminating the need for separate “indoor-only” and “outdoor-only” fixtures. Handling and setup are made simple with ergonomic handles on the head and base, Omega bracket attachments for rigging, and a sealed design that keeps out dust and pollutants—reducing cleaning and upkeep over time.
Optical enhancements are at the core of the MAC Aura XIP. Its tighter zoom delivers higher-intensity beams with minimal stray light. The fixture supports LED frequency control for flicker-free video output and offers green/magenta shift adjustments for optimal color temperature control, especially valuable in broadcast applications. It offers a rich color palette powered by RGBW LEDs that produce both vivid saturated tones and soft pastels, all calibrated for consistent and high-quality output.
Beam pixel control is another key feature. The MAC Aura XIP allows video mapping directly onto individual beam pixels and aura filaments using the Martin P3 controller. This brings a new dimension to creative design with striking stage effects and animated lighting patterns. The aura filament effect is powered by twelve individually controllable RGBW filaments that can display bright, distinctive backlight visuals and deliver stunning visual accents.
In terms of wash quality, the MAC Aura XIP leads its class with a clean and even field. It uses seven RGBW beam LEDs and twelve RGBW aura LEDs to deliver 6,000 lumens of rich output with a soft edge and zero hotspot. The included Softlens accessory enhances the wash further by softening edges with minimal impact to the aura effect, and it can remain attached even during transport.
Advanced control capabilities make the MAC Aura XIP easy to integrate into sophisticated lighting setups. It supports DMX, Art-Net, sACN, RDM (including over Art-Net), and Martin P3. Control is further enhanced with a battery-powered interface for offline addressing, a full suite of DMX profiles, and automatic protocol detection. For pixel mapping, the P3 Mix function allows smooth blending between video and DMX looks.
This fixture includes a full range of dynamic effects, including over 200 built-in macros with control over color layers, movement speed, and direction. Additional features include variable zoom (6.3°–50.4°), pan (540°), tilt (220°), and precise dimming and strobe controls across both beam and aura elements. Users can fine-tune the color output with variable CTC (2,000–12,850 K), tint control, tungsten emulation, and virtual color wheels with 48 presets.
The MAC Aura XIP is constructed with durability and performance in mind. It features a high-impact, flame-retardant housing rated IP54 for weather resistance. Despite its ruggedness, it remains lightweight at just 8.95 kg and compact in size. Mounting options are flexible with multiple rigging points, and all connectors—including DMX, Ethernet, and power—use locking Neutrik TOP components for secure and weatherproof connections.
Electrically, the unit supports a wide voltage range (100–240 V AC) and includes an efficient power supply with a low idle and hibernation draw. Its cooling system is temperature-regulated and ultra-quiet, achieving a theater-friendly noise level of just 25.2 dB(A) in broadcast mode. Thermal specs ensure performance in extreme temperatures, from -10° C to 40° C, with efficient heat dissipation.
With a maximum output of 11,000 lumens, peak intensity of 360,000 cd, and precise calibration across multiple color modes, the MAC Aura XIP is a professional-grade solution for designers and rental companies seeking an advanced wash fixture that excels in any environment—indoor or out.
