The Martin Exterior Dot-HP Pro is a powerful, outdoor-rated RGBW LED node designed for large-scale media façades, architectural accents, and long-distance viewing applications. Featuring a bright and color-rich output, each unit is meticulously calibrated for color and brightness uniformity, ensuring a consistent visual experience across expansive installations. Whether integrated into building perimeters, landmarks, or architectural structures, the Exterior Dot-HP Pro delivers dynamic video and lighting effects with precision and impact. It supports control via Martin’s P3 System Controllers as well as sACN and Art-Net protocols, offering flexible compatibility with industry-standard lighting networks.
Designed for creative flexibility, the Exterior Dot-HP Pro is ideal for integrating LED video into façades and indoor or outdoor environments. Its hybrid In/Out connector design simplifies installation, while the system’s intuitive setup through the Martin P3 platform eliminates complex addressing and mapping. The fixture includes 16 RGBW LEDs, achieving a luminous intensity of up to 106 candela (clear front), and supports a wide color temperature range from 2,000 to 12,000 K. It also features built-in effect macros and a dedicated color temperature control channel, giving lighting designers extensive creative options without requiring external processing.
Engineered to perform in demanding environments, the Dot-HP Pro boasts an IP67-rated, fully weatherized housing with IK08 impact resistance and a C5 High corrosion rating. Its durable construction includes a 78 mm diameter footprint and either a clear or diffused dome front, supporting wide viewing angles of up to 180 degrees. The fixture is constructed from anodized, powder-coated cast aluminum in standard Traffic Grey, with custom colors available upon request. It is vibration-tested and designed to endure harsh conditions in both architectural and entertainment settings.
The Exterior Dot-HP Pro can be powered via Martin P3 PowerPorts or compatible 48 VDC power supplies, with data and power delivered through a single, hot-pluggable DCE connector cable. Up to 68 units can be daisy-chained in full power mode, or up to 125 in reduced power mode. Its robust electrical system includes 4 kV surge protection and energy-efficient operation, drawing just 5.7 W at full output and only 1.5 W in hibernation mode. Control options include Martin P3, Art-Net, and sACN, with automatic protocol detection and full RDM support over Art-Net for configuration and real-time monitoring.
With 16-bit control resolution via P3 and comprehensive DMX channel options, the Exterior Dot-HP Pro provides fine-grain management of color and intensity. It is compliant with all major networked lighting standards and integrates seamlessly into modern lighting ecosystems. The system also supports stand-alone programming of up to 20 scenes, enabling flexible deployment scenarios. Shipped in sustainable FSC-certified packaging and backed by a five-year warranty, the Exterior Dot-HP Pro stands out as a forward-thinking solution for architects, lighting designers, and integrators seeking to push the boundaries of creative video and lighting design.
