Omega Moduline is a sleek and high-performance recessed cellular LED panel designed to meet the demands of modern office and educational environments. Combining style, sustainability, and upgradability, it is engineered to deliver exceptional lighting while remaining easy to install and maintain. The panel is available in three sizes—600 x 600 mm, 625 x 625 mm, and 300 x 1200 mm—each featuring two replaceable linear LED modules. Each module houses 12 cells with primary lens optics, offering controlled, low-glare illumination (UGR <19) with a high efficacy of up to 153 lm/W. Colour temperature options include 3000 K, 4000 K, or Variable Colour Temperature (VCT) ranging from 2700 K to 6500 K, providing versatility for different applications. Lumen outputs of up to 5000 lm ensure that spaces are brightly lit without compromising comfort, while optional emergency batteries and multiple control options, such as DALI, basicDIM Bluetooth® Wireless, presence detection, and daylight dimming, enhance functionality.
The panel’s cellular design features deep recessed cells with primary lenses that maintain glare control even at high lumen outputs, delivering an outstanding combination of optical performance and energy efficiency. Each linear LED module is replaceable using a tool-free click-in mechanism and quick, easy wiring connection, allowing for sustainable upgrades over the panel’s lifetime. Modules can be swapped to change colour temperature or colour rendering, providing flexibility if the room’s purpose changes or when maintenance is required, eliminating the need to replace the entire luminaire.
Omega Moduline is designed for recessed lay-in ceilings and, with a maximum depth of only 33 mm, is ideal for shallow ceiling voids. Additional mounting accessories allow for installation in concealed ceilings or for surface-mounted and suspended configurations, making it a highly adaptable solution for a wide range of interiors.
Lighting controls are fully integrated to adapt to the needs of occupants. Optional Microwave Sensors (MWS) provide motion-triggered on/off functionality, ensuring lights operate only when spaces are occupied. PIR dual sensors (HFSX) combine presence detection with daylight dimming, maintaining a consistent surface illuminance (e.g., 500 lux) by balancing artificial and natural light, which reduces energy consumption while maintaining comfort. The HFSX system can also include a leader-follower function, allowing one sensor to control multiple luminaires within its detection area, creating efficient local lighting networks.
The panel is also compatible with basicDIM Bluetooth® Wireless, a sophisticated built-in wireless control system that integrates sensors, switches, and luminaires. Configured via smartphone or tablet, basicDIM allows grouping of luminaires, scene setting, dimming adjustments, colour temperature tuning, and presence or daylight sensor integration. Being wireless, it is equally suitable for new installations and building refurbishments, and installation is simplified as all necessary control technology is integrated into the panel with no additional wiring required.
Variable Colour Temperature (VCT) functionality allows the panel to tune light from warm 2700 K to cool 6500 K, ensuring the right lighting for tasks, moods, or architectural requirements. This feature, combined with high-quality LEDs, ensures longevity, sustainability, and adaptability. The modular design also supports replacement of drivers and sensors, making the panel an environmentally friendly, upgradeable solution with prolonged lifetime when maintained carefully.
Materials and finishes are chosen for durability and aesthetics. The frame is made from mild sheet steel finished in white (RAL9016), LED modules are molded plastic, and optical components are crafted from high-quality plastic lenses. All sensors, controls, and emergency options are neatly integrated into the panel, with a gear tray on the back for compact storage and easy access.
Omega Moduline is suitable for lay-in and concealed ceilings, and with optional accessories, it can be surface-mounted or suspended. Each LED module is designed for tool-free replacement with a simple click-in mechanism. Available in multiple sizes and lumen packages (3300, 4100, and 4800 lm) with colour temperature options of 3000 K, 4000 K, or VCT 2700–6500 K, and CRI options of 80 and 90, the panel provides customizable, high-quality lighting. The combination of deep cellular lenses, low-glare optics, and replaceable modular components makes Omega Moduline a sustainable, high-performance solution for offices, classrooms, and professional environments where flexibility, efficiency, and occupant comfort are essential.
https://www.thornlighting.com/en/products/indoor-lighting/recessed-modular-luminaires/Omega_Moduline
