The FUZE PENDANT WH™ is a professional-grade lighting solution designed to deliver powerful, high-quality illumination for a wide range of house and area lighting applications. Engineered with performance and flexibility in mind, this versatile fixture outputs up to 11,000 lumens, making it ideal for large venues, high-ceiling environments, and architectural spaces requiring bright, consistent light. Despite its impressive output, the fixture maintains a compact and elegant form factor, ensuring adaptability in smaller or more intimate settings as well.
At the heart of the FUZE PENDANT WH is a 230W RGBWL (Red, Green, Blue, White, Lime) 5-in-1 LED array, which offers full-spectrum color mixing with an extended CCT range of 2400K to 8500K. With a CRI of 90 at 3200K, it produces crisp, natural whites and subtle pastels, as well as powerful saturated hues. Its 16-bit dimming control delivers smooth fades and dynamic lighting effects, while a range of user-selectable dimming curves and a high-speed electronic shutter provide precision for theatrical and architectural lighting designers alike.
One of the standout features of the FUZE PENDANT WH is its fanless convection-cooled design, which ensures completely silent operation. The fixture contains no moving parts, making it a reliable, maintenance-free solution suitable for sensitive environments like houses of worship, theaters, and museums. A 45° lens is included, while optional lenses in 25°, 40°, 50°, 85°, and 100° angles are available, offering precise control over beam distribution for tailored lighting solutions.
Designed for both permanent installations and temporary applications, the FUZE PENDANT WH supports multiple control protocols including DMX, RDM, 0-10V, and Elation’s E-FLY™ extended range wireless DMX. The fixture is equipped with industry-standard locking 5-pin XLR and IP65 locking power connectors, as well as bare wire terminal blocks for power, control, and 48V emergency battery input, accommodating diverse installation requirements with ease. Its built-in OLED display and four-button menu panel make configuration and setup fast and intuitive.
Physically, the fixture measures 12.5 inches in length and 7.8 inches in diameter, weighing 15.8 lbs (7.2 kg). It consumes a maximum of 230W, and operates in ambient temperatures ranging from 14°F to 113°F (-10°C to 45°C). The FUZE PENDANT WH is rated IP20 and certified to CE, cETLus, and FCC standards, ensuring it meets the demands of professional installations.
For even greater customization, a full line of optional accessories is available, including interchangeable lenses in various beam angles to meet any lighting design need. With its combination of high output, silent operation, full-spectrum color, and professional-grade control options, the FUZE PENDANT WH is an advanced and adaptable solution for environments that demand both performance and aesthetic excellence.
