The KL PROFILE FC is a professional-grade, full-spectrum LED ellipsoidal lighting fixture designed for a broad range of precision applications in theatrical, studio, and live production environments. Equipped with a powerful 305W RGBMA LED engine, this compact unit delivers exceptional color performance, a high CRI of 93.5, and over 10,000 lumens of output. Its finely tuned Red, Green, Blue, Mint, and Amber LED sources ensure stunning color accuracy, natural skin tones, and smooth color rendering across the spectrum, making it an ideal choice for any venue demanding rich, nuanced lighting.
One of the standout features of the KL PROFILE FC is its integrated manual zoom range from 6° to 50°, eliminating the need for additional lens tubes and simplifying rigging and deployment. The optical design is enhanced with precision lens coatings to ensure razor-sharp imaging and eliminate chromatic aberrations or color shifting, regardless of zoom, focus, or framing blade settings. Additionally, a manual iris is built in to provide even greater beam control for detailed lighting designs.
For creative versatility, the fixture includes a 16-bit rotating and indexing glass gobo slot that is easily accessible from the top of the fixture. It ships with the KL Profile Designer Gobo Set, featuring 10 high-resolution patterns. The fixture also supports an optional Fresnel Wash Lens Conversion Kit, transforming it into a soft wash light while maintaining uniform spacing and aesthetics in multi-fixture installations. The full blackout framing system includes four rotating blades and full barrel rotation for accurate beam shaping.
Color capabilities are expansive with RGBMA color mixing, variable CCT control from 2400K to 8500K, and both CMY and RGB emulation modes. Additional tools include a virtual gel library and magenta/green shift adjustment, ensuring it integrates seamlessly with broadcast, film, and stage environments. Users can fine-tune color and intensity manually using onboard encoders and an intuitive full-color LCD menu, or through DMX and RDM protocols with support for multiple channel modes and LED refresh rate adjustments. Elation’s internal E-FLY™ wireless DMX transceiver provides added flexibility for modern control environments.
Designed for reliability, the KL PROFILE FC includes IP65-rated locking power connectors, rugged construction, and silent operation with advanced fan management including a mute mode for noise-sensitive spaces. Its 7.5" front accessory slot accommodates industry-standard accessories, and the fixture ships with a gel frame while supporting additional mounting options like the Omega Bracket.
Ideal for theaters, houses of worship, corporate events, and television studios, the KL PROFILE FC offers an exceptional combination of flexibility, performance, and ease of use. With its extended zoom range, high output, and robust color system, it is built to deliver consistent, high-quality results in any demanding lighting environment.
