The Model 8910 Evolution 2 from J.W. Speaker delivers an advanced 5x7" LED headlight engineered for high-performance applications, now available with SmartHeat® heated lens technology and Dual Burn® optics. This cutting-edge headlight is a drop-in replacement for standard rectangular headlights used in heavy-duty trucks, offering a plug-and-play solution with enhanced visibility, rugged durability, and street-legal certification across DOT, ECE, and military standards. Designed to withstand extreme environments, the headlight features a tough die-cast aluminum housing and polycarbonate lens, offering superior thermal and condensation management while resisting salt spray and harsh elements.
A key highlight of the 8910 Evolution 2 is the integrated Dual Burn® technology, which delivers a high-beam performance unlike any standard LED light. It combines the high-beam and low-beam optics simultaneously, resulting in a wider, brighter, and more effective beam pattern that significantly improves visibility and safety in low-light or nighttime conditions. To further enhance operational safety in cold climates, the optional SmartHeat® heating system automatically de-ices the lens based on ambient temperature. Using a thermally-conductive grid, it reacts in real-time to weather changes, ensuring a clear lens surface without any driver intervention. This system can de-ice the lens up to twice as fast as standard heated headlights.
Built with performance and compliance in mind, the Model 8910 Evolution 2 is designed to meet proposed National Highway Transportation Safety Administration (NHTSA) guidelines for a 5-Star NCAP-compliant low-beam headlight. It excels in three core performance metrics: optimized light output measured in lux, reduced glare through superior beam control, and compliant light placement for safety in designated mounting locations. Whether you select the heated or non-heated version (Model 8900 Evolution 2), both models meet rigorous international safety and quality standards.
Engineered for a wide range of applications—including agriculture, automotive, construction, industrial, mining, off-road 4x4, rail, and commercial trucking—the 8910 Evolution 2 supports operating voltages between 10-32V DC and transient spike protection up to 150V. The headlight is compatible with DRL systems and includes dedicated wiring for low beam, high beam, ground, and ECE front position lighting (the latter required outside North America). In U.S. and Canadian markets, the red front-position wire is typically unused.
With current draws of 5.35A (high beam) and 4.30A (low beam) at 12V DC, and 2.50A (high beam) and 2.10A (low beam) at 24V DC, the headlight delivers powerful illumination without overloading vehicle electrical systems. The 8910 Evolution 2 represents a leap forward in LED headlight technology for commercial vehicles, off-roaders, and specialty fleets where dependable lighting is essential to safety, visibility, and productivity.
