The Transom LED troffer light redefines recessed lighting through the use of vertical Anidolic optics, offering a luminous yet transparent appearance that delivers exceptional visual comfort. Its innovative vertical optical structure, crafted from clear anodized extruded aluminum, allows the luminaire to sit discreetly within a space, blending seamlessly into contemporary interiors. When illuminated, the fixture appears almost fenestration-like—transparent and clean—while still producing effective, controlled lighting.
Engineered for high performance and energy efficiency, Transom delivers approximately 37 footcandles in typical open office applications with an energy density nearing 0.3 W/ft². This makes it a superior choice for sustainable lighting, combining minimal energy consumption with strong illumination metrics. Its use of linear Anidolic optics—specifically designed for LED sources—ensures glare-free, wide distribution lighting that complements modern architectural aesthetics.
Transom’s form and functionality are matched by its flexibility. The troffer is compatible with both T-grid and drywall ceilings and is available with optional trim or trimless flange kits for a tailored fit. The family includes a complete range of recessed configurations that can be used individually or in grouped compositions while maintaining consistent design language. The 2x2 format offers a compact solution ideal for spaces with reduced plenum height, while still benefiting from the same optics, wattage, and CCT options as the full Transom line.
Constructed with a clear anodized aluminum lower rail and a formed 22-gauge steel housing, Transom ensures durability and reliability. It includes an integral quick wire access plate and seismic restraint tabs for code-compliant installations. Its optical performance is driven by Anidolic light extraction elements paired with precision-molded, high-transmittance acrylic lenses. The long-life LED system is rated for ≥L90 at 60,000 hours and available in 3000K, 3500K, and 4000K with CRI options of ≥80 (R9≥0) or ≥90 (R9≥50), with tight binning for color accuracy (≤2 SDCM).
The electrical design features integral high-efficiency drivers for 120–277V and 347V applications, with power factor >0.90 and THD <20%. Dimming capabilities range from a standard 3% down to optional 1% or 0.1%, ensuring flexible light output for varied applications. Surge protection meets ANSI and IEEE standards, and inrush current is compliant with NEMA 410. Optional 6-foot prewired flex whips simplify installation.
For emergency scenarios, Transom offers an optional battery pack delivering 10W Class 2 output for 90 minutes, producing 1150–1750 lumens depending on system efficiency. A Generator Transfer Device (GTD) is also available, which overrides 0–10V controls during power loss to ensure full output operation in emergency mode.
Transom is designed for use in dry or damp indoor environments with ambient temperatures ranging from 0–30°C (32–86°F). It must be protected from aggressive chemicals like chlorine, solvents, ammonia, and alcohol. Not intended for natatorium applications, it should be cleaned only with a slightly damp, soft cloth to maintain longevity.
This troffer light carries a 5-year limited warranty covering components and workmanship. It is thoroughly tested per IESNA LM79 and LM80 protocols (LEDs at 9,000 or 10,000 hours) and meets a wide range of safety and performance certifications including UL (US and Canada), CCEA Chicago Plenum, IC Rating, and DesignLights Consortium® qualification (check QPL listings). Additionally, Transom is Living Building Challenge (LBC) Declared, aligning with sustainable and future-focused architectural design requirements.
Altogether, the Transom LED troffer light provides a highly flexible, optically advanced, and visually refined lighting solution for commercial and institutional environments, bridging the gap between minimalist architecture and technical excellence.
