The ADJ Focus Flex L7 is a versatile moving head fixture designed to provide lighting designers with the creative flexibility to produce vibrant washes, sharp beams, and stunning pixel effects all from one compact and highly efficient unit. Powered by seven 40-watt 4-in-1 RGBL LEDs, each of which can be controlled independently, the fixture offers an impressive color range and a motorized zoom function that enables beam angles between 6 and 55 degrees. This range of flexibility allows for broad washes and tight, focused beams, making it ideal for various lighting applications in event production, rental services, and permanent installations in venues such as concert halls, theatres, nightclubs, and churches.
The Focus Flex L7 delivers exceptional output thanks to its RGBL color mixing capabilities, which provide a vast array of color possibilities. The addition of the lime chip to the red, green, and blue LEDs enhances color rendering and allows for a higher CRI of 84, resulting in more accurate and natural colors, especially when used for illuminating performers or décor. The fixture’s Virtual CMY mode offers seamless integration with other CMY color-mixing fixtures, while the virtual foreground and background color wheel control further enhance creative options. The fixture also features a white light output with a variable color temperature range of 2700K to 10,000K, which can be adjusted via linear control or pre-set options. Additionally, the independent control of the seven LEDs enables dynamic pixel-mapped effects, providing lighting designers with a powerful tool for creating visually captivating displays.
The fixture’s motorized zoom system allows users to remotely adjust the beam angle, with the option to quickly switch between a narrow 6-degree beam and a wide 55-degree field angle. This capability, combined with the fixture’s rapid motor movement and 16-bit fine motor control, allows for high-impact aerial effects and precise beam positioning. It is also equipped with seven different DMX modes, offering a wide range of control options depending on the needs of the application. The fixture’s customizable settings, such as selectable dimming modes, dimming curves, and LED refresh rates, ensure that the Focus Flex L7 can meet the specific requirements of any production, from stage lighting to broadcast and video applications.
Designed with efficiency in mind, the Focus Flex L7 is equipped with energy-efficient LEDs that offer a long operational life of 50,000 hours, reducing maintenance costs and eliminating the need for frequent lamp replacements. These LEDs also generate less heat, ensuring that the fixture remains comfortable for performers and crew. Its low power consumption (337W at 120V) further enhances its appeal for both rental and installation applications, where power efficiency is a key consideration.
The fixture is housed in a compact, lightweight casing, measuring just 9.17" x 6.97" x 13.8" and weighing 15.5 lbs, making it easy to transport, store, and rig. Despite its small size, the Focus Flex L7 offers a powerful output of 3,500 lumens, and its versatility extends to its wireless capabilities. The built-in WiFLY EXR wireless DMX protocol allows for remote control of the fixture over distances of up to 2,500 feet, eliminating the need for cumbersome cables. The unit also features a USB port for easy firmware updates, ensuring that users can keep the fixture up-to-date with the latest features and enhancements.
As with all ADJ products, the Focus Flex L7 is designed with ease of use in mind. A color LCD display with a 6-button interface allows for intuitive setup and control, and the fixture supports RDM (Remote Device Management) for remote addressing and monitoring. Whether used in rental applications or as part of a permanent installation, the Focus Flex L7’s compact design, high performance, and flexible control options make it an invaluable tool for lighting designers looking to enhance their productions.
With its powerful features and flexible design, the Focus Flex L7 is a standout addition to ADJ's range of professional lighting fixtures, following the success of the original Focus Flex model. Its increased output, improved CRI, and enhanced versatility make it a great choice for both lighting rental companies and permanent installations, providing a high-performance solution for any lighting professional.
