The ElectraPix Par 7 Pak is a complete, road-ready lighting solution that delivers high-performance wash lighting with the convenience of wireless operation and in-case charging. This package includes six battery-powered ElectraPix Par 7 LED fixtures housed in a rugged flight case, which also serves as a charging hub with dedicated slots for each light. Designed for production professionals and rental operations, the Pak is ideal for applications where portability, speed of deployment, and impactful lighting are essential. A locking power cable connects directly to the side of the case, enabling all six fixtures to charge simultaneously while remaining safely stored.
Each ElectraPix Par 7 fixture within the Pak features a 17-degree beam angle and is equipped with seven high-output, color-calibrated 20-Watt RGBAL+UV LEDs that deliver vibrant, full-spectrum color mixing. These primary LEDs are surrounded by 29 background glow LEDs, housed behind opaque plastic to produce a soft ambient effect, enhancing creative design options. The fixtures also include a gel frame and a diffusion filter to broaden the beam and soften the output, providing flexibility for different event environments. The included UC-IR24 remote control simplifies operation, allowing users to quickly access color presets and settings without requiring a DMX console.
As part of the broader ADJ ElectraPix Series, the ElectraPix Par 7 shares advanced features with its linear counterparts—the ElectraPix Bar 8 and Bar 16. Each fixture in the series utilizes color-calibrated 20-Watt RGBAL+UV LEDs to offer a powerful, uniform wash of color. The lime component enhances CRI and allows for precise variable white adjustment from 2,700K to 9,900K, while the UV LED can be used on its own for dramatic blacklight effects or mixed with other colors to create vivid, saturated hues such as hot pink and electric blue.
Surrounding each primary LED is a cluster of 0.2-Watt RGB LEDs that provide a dynamic background glow, extending the creative palette for lighting designers. With foreground/background color macros built-in, programming is fast and intuitive. All ElectraPix fixtures support Aria X2, ADJ’s wireless DMX management system, which enables reliable wireless control, remote fixture configuration, and over-the-air firmware updates.
Robust and road-ready, every ElectraPix unit features an IP65-rated housing for safe outdoor use in any weather. They are powered by high-capacity internal lithium-ion batteries for cable-free operation but also include standard locking power connections for extended use. For ultimate convenience, each model can be charged using dedicated base plates, many of which are integrated into their respective flight cases for efficient transport and deployment.
The ElectraPix Bar 8 and ElectraPix Bar 16 offer the same advanced feature set in linear formats. The Bar 8, a 0.5-meter fixture, contains eight main LEDs and 32 background LEDs. The Bar 16, at 1 meter in length, doubles that with 16 main LEDs and 66 background LEDs. Both are equipped with a 17-degree native beam angle, a 20-degree diffusion filter, a removable glare shield, and variable-angle mounting brackets. Their built-in L Track rigging system allows for quick attachment to trussing or floor setups, and locking end-to-end connections provide seamless alignment across multiple fixtures.
For greater flexibility in setup, the optional Accu-Stand VFB1 base plate can support up to two Bar 16 units or a combination of Bar 8 and Bar 16 fixtures with a total of 32 primary LEDs. Like the Par 7 Pak, the Bar 8 Pak and Bar 16 Pak each include four fixtures and a custom flight case with integrated charging ports, storage space for accessories, and an included remote control.
From vibrant concert stages to sophisticated event uplighting, the ElectraPix Series delivers unmatched versatility, creativity, and convenience. As Alfred Gonzales, ADJ USA’s Director of Sales, notes, “Each model offers the creative versatility of individually controllable hex color LEDs, which incorporate both lime and UV chips, as well as background RGB glow LEDs. This is combined with the practical versatility of rechargeable batteries, Aria X2 wireless, IP65-rated casings and L Track rigging to provide LED wash fixtures ready for any stage or event.”
