The ADJ COB Cannon LP200ST is a powerful and versatile professional wash lighting fixture designed to meet the demands of both permanent installations and temporary event productions. At the heart of the fixture is a high-output 200-Watt COB (Chip On Board) LED engine that combines red, green, blue, amber, and lime LED chips to produce an extensive color palette with vibrant saturation and a high CRI of over 90. The addition of the lime chip enhances certain hues, boosts white light quality, and expands the fixture’s tunable white color temperature range from 2300K to 9900K. With an estimated LED lifespan of 50,000 hours, the LP200ST is both efficient and low maintenance.
Offering a generous native beam angle of 80 degrees, the COB Cannon LP200ST is ideal for washing large areas with smooth, even light. For greater flexibility, it comes with a lens kit that includes 40-degree and 50-degree lens options, allowing users to quickly narrow the beam spread as needed. The fixture also supports optional barn doors for precise light shaping and control. Compact and lightweight at just 9.26 lbs. (4.2 kg) and measuring 13” x 10” x 7.5” (330 x 256 x 190mm), the LP200ST is easy to rig, transport, and store. A robust scissor yoke provides flexible mounting options, functioning as either a hanging bracket or a floor stand, and an Omega bracket is also included for pendant mounting.
Designed with professional control in mind, the COB Cannon LP200ST offers both 3-pin and 5-pin DMX input and output connections, as well as locking power input and output sockets to daisy chain up to three units on a single outlet. It features a USB service port for firmware updates and can also be controlled using the included ADJ UC IR remote for quick, wireless color selection. The onboard OLED display and intuitive menu system with four push buttons allow for easy navigation of fixture settings.
For DMX control, the LP200ST provides a wide selection of 10 different channel modes (5 to 21 channels), offering flexibility to match varying programming needs. It supports full RGBAL color mixing, linear white color temperature control, and remote access to 64 built-in color macros. Users can choose from 6 dimming modes and 4 dimming curves, adjust dimming speed via DMX, and fine-tune the LED refresh rate with 14 selectable presets ranging from 900Hz to 25,000Hz to avoid flicker in video applications.
The COB Cannon LP200ST represents a significant evolution in ADJ’s popular COB Cannon Series, introducing enhanced output and color flexibility through its upgraded light engine and lime chip integration. “ADJ’s COB Cannon Wash fixtures utilizing COB LED engines have proved extremely popular with both integrators and equipment rental/production companies for a number of years,” says Alfred Gonzales, ADJ USA’s National Sales Manager. “Now, with the new COB Cannon LP200ST, we’ve boosted the wattage of the LED engine and added a lime chip. This gives the fixture a higher CRI output, plus it allows lighting designers to be more flexible with the option of a full gamut of colors as well as tunable white color temperatures for properly lighting people of all skin tones.”
With its robust features, compact form, and exceptional output quality, the COB Cannon LP200ST is ideally suited for house lighting, stage washes, décor illumination, and more. Whether used in a church, theater, concert venue, or event space, this fixture offers professional-grade performance in a durable and user-friendly package.
