24V RGB LED Pixel Tiles for Pixel Mapping, Video Synchronization, and Interactive Visual Content

LED pixel tiles deliver a powerful, customizable solution for dynamic lighting displays across architectural, commercial, and creative applications. Each RGB+6500K rigid pixel tile is engineered for versatility, measuring 140mm x 140mm (5.5in x 5.5in) and operating at 24V DC. Compact yet impactful, these tiles can be surface mounted directly or seamlessly integrated into SEG frame systems, making them highly adaptable for both permanent installations and temporary setups.

Designed with precision PixelControl technology, each tile is divided into four quadrants, with nine LEDs per quadrant functioning as an independent pixel. This configuration allows a single tile to require 16 addresses for full control, enabling designers to create sophisticated animations, smooth gradients, and intricate pixel-mapped effects. For extended installations, additional power injection is required for every six tiles connected, ensuring stable performance across large-scale projects.

Ease of installation is a core feature of these pixel tiles. Built-in SM connectors allow for simple linking between tiles, while the input direction is clearly indicated for hassle-free setup. Each tile includes integrated mounting holes, which can be used independently or in combination with a channel system, providing flexible mounting options. The design is fully compatible with SEG frame systems, offering a clean and professional finish in both commercial and decorative applications.

With PixelControl technology powered by a UCS2904 IC chip, the tiles support up to 32 tiles per DMX universe, ensuring precise synchronization and control. Operating at 24V, they support convenient power linking for up to six tiles, reducing wiring complexity. Their RGB spectrum (625/520/465nm wavelengths) combines with the 6500K white to produce a wide range of vibrant, customizable colors suitable for both functional and artistic use.

These pixel tiles are an ideal choice for applications where lighting must blend creativity with reliability. From enhancing architectural aesthetics to creating engaging retail displays, immersive event lighting, signage, interior design accents, or art installations, they offer both visual impact and ease of integration. By combining advanced pixel-mapping capabilities with straightforward installation, LED pixel tiles stand out as a premier tool for designers seeking a versatile, high-performance lighting solution.

https://www.environmentallights.com/20873-tl140-px-rgb65k-24v-4p.html
