The ILBLP CP15 HE SD N from IOTA is a UL Listed LED emergency driver that allows a single LED fixture to serve both normal and emergency operation. In the event of a power failure, the driver automatically switches power from the standard AC driver to the unit’s internal battery, sustaining operation for 90 minutes. The unit integrates a battery, charger, and converter circuit within a narrow-profile enclosure, allowing installation within channel spaces or wireways. Utilizing lithium iron phosphate battery technology, the ILBLP CP15 HE SD N achieves a significantly reduced form factor without compromising output, while its standard automatic monthly and annual self-testing functions ensure compliance with code requirements.
Operating at a constant 15 Watts with a nominal output of 20-55 VDC, the ILBLP CP15 HE SD N maintains stable power delivery throughout the full emergency runtime. This constant wattage performance prevents any reduction in illumination, guaranteeing reliable emergency lighting when needed. Its compact lithium battery and narrow enclosure design minimize mounting footprint, allowing flexible installation even in constrained spaces, while maintaining consistent output performance.
Safety and code compliance are integral to the ILBLP CP15 HE SD N. The unit features built-in self-diagnostics and self-testing, with monthly and annual routines that satisfy NFPA 101 periodic testing requirements. Visual indicators provide immediate confirmation of system readiness. It is UL 924 Listed and classified to FTBV, with Auto-Sense 20-55 VDC output certified to UL 1310 and Class 2 compliant. The unit is suitable for both field and factory installation across the United States and Canada, supporting use with switched or unswitched fixtures. The white-painted steel enclosure includes a single-piece TBTS test switch and charge indicator accessory kit for easy installation and operation.
The ILBLP CP15 HE SD N meets or exceeds all NEC, IBC, and Life Safety Code emergency lighting requirements and is certified for CA Title 20, with registration in the Modernized Appliance Efficiency Database (MAEDBS). It is suitable for a variety of environments, including plenum spaces, damp locations, recessed Type IC luminaires, and enclosed or gasketed luminaires. RoHS compliant, the unit ensures environmentally responsible design.
Electrical and operational specifications include a 120-277 VAC voltage rating, 50/60 Hz frequency, and a maximum operating temperature of 55°C with a minimum of 0°C. Battery runtime is 90 minutes with a 24-hour recharge period, activated automatically by AC power. The ILBLP CP15 HE SD N comes with a five-year warranty, offering reliable, code-compliant emergency LED performance for a wide range of commercial and industrial lighting applications.
