The Micro Ring II™ Vertical Suspended fixture reimagines the classic ring design by adopting a striking vertical orientation, resulting in an exquisite pendant that exudes timeless elegance. Its sleek and slender profile evokes the charm of graceful suspended jewelry from refined occasions, making it perfect for creating captivating clusters and cascading arrangements when multiple pendants are grouped together. This dynamic design element enhances the visual appeal of any space, establishing a compelling focal point that draws the eye and elevates the ambiance.
Performance-wise, the Micro Ring II Vertical sets a new benchmark among decorative rings with a best-in-class lumen efficacy of 105 lumens per watt. This impressive metric reflects not only brightness but also superior light quality. A high-efficiency, flexible diffuser fits snugly within the frame, preventing any light leakage and ensuring a uniform, seamless diffusion of light that complements and enhances the overall aesthetic of the environment.
To accommodate a broader spectrum of design needs, a lower output version of the Micro Ring II Vertical is now available. This model caters to settings requiring subtler, more atmospheric lighting while maintaining the celebrated quality and uniformity of light diffusion. Ideal for creating intimate moods or when a gentler lighting presence is preferred, this option broadens the versatility of the Micro Ring collection, ensuring a fitting solution for virtually every decorative lighting challenge.
The fixture’s body is crafted from aluminum and finished with a durable powder coating, offering both strength and style. It features a silver braided power cable that complements its refined appearance. The diffuser uses a protruding lens measuring 0.08 inches (2.1 mm) to precisely manage light output and diffusion.
An optional remote emergency lighting system is available, providing 1.5 hours of emergency illumination in North America and 3 hours in Europe. This system includes an inverter module, NiCad batteries, and a remote wall or ceiling-mounted LED charge indicator and test switch (North America only). The test switch fits a standard single gang box (not supplied), and the maximum allowable distance between the luminaire and the emergency system’s wall or ceiling plate is 15 feet (4.5 meters).
The lighting drivers are remote, high power factor (HPF) electronic drivers compatible with 120-277V and 347V in North America, and 240V in Europe, supporting dimming functionality. Wiring distance varies by gauge: 18 AWG supports up to 40 feet (12.2 meters), 16 AWG up to 60 feet (18.3 meters), and 14 AWG up to 90 feet (27.4 meters). Drivers must remain accessible after installation and may be either remotely mounted or integrated within the canopy depending on the fixture size.
Suspension is accomplished using steel cables, including SS1 and SS3 options, with Power Over Suspension (SS6) available for added integration capabilities. The Micro Ring II can also be connected to data networks via Power over Ethernet (PoE), allowing for smart control and networked lighting solutions. For sensor compatibility, consultation with the factory is recommended.
Mechanically, the luminaires mount directly over a J-box, which is supplied by others, and this mounting approach applies to North America only. The fixture boasts a long lifespan with an L70 rating of over 60,000 hours at 25°C (77°F). Delivered lumens and lumen-per-watt performance are based on white LEDs at 4000K with a minimum color rendering index (CRI) of 80.
The Micro Ring II Vertical is rated for damp locations, making it suitable for environments with moisture exposure. For seismic compliance, bracing kits are available, and interested parties should consult the factory for details to ensure adherence to local codes and regulations.
