MOD 2.0 URBAN represents a versatile architectural street lighting solution suitable for a wide range of urban contexts. Its three different types of fixings allow installation in multiple configurations, making it adaptable to various street, square, and park layouts. With a combination of rigorous, linear geometric shapes and elegant proportions, this luminaire contributes to a coherent and sophisticated urban landscape. The design is recognized for its balance of aesthetic refinement and technical performance, providing excellent visual comfort for both pedestrians and vehicles while harmonizing with the surrounding environment. Available in two height versions, MOD 2.0 URBAN is highly appreciated by architectural firms for its combination of style and functionality.
The luminaire is specifically suited for urban environments such as parks, city centers, squares, residential areas, and pedestrian zones. Its refined form and high-quality construction have established it as a popular choice for modern urban planning projects. Beyond visual appeal, the system incorporates AEC dimming solutions that allow precise adjustment of luminous flux, enabling custom lighting scenarios tailored to each installation. These adjustments improve visual comfort while contributing to significant reductions in operational costs, ensuring that the light levels are appropriate for the area and application.
MOD 2.0 URBAN also incorporates smart and connected public lighting capabilities, supporting the creation of intelligent city networks. These luminaires serve as nodes in a connected infrastructure, capable of integrating intelligent technologies that contribute to the development of Smart Cities. Their design supports the reduction of light pollution, controlling upward emissions to preserve the night sky, a feature recognized by the Australian Dark Sky Alliance (ADSA) award.
The MOD 2.0 URBAN 200 version has a compact profile with dimensions of 200×80 mm and is available in lengths ranging from 350 mm to 950 mm. It supports a wide range of optical configurations, including STE-M/S for suburban streets, STU-M/S for urban and cycle-path lighting, STW for wide roads with wet surfaces, SV/SV2 for narrow streets and highway turns, S05 for streets, urban, and green areas, OP-DX/SX for crosswalks, STA/STA1 for V and P categories, and ASP/ASC for floodlighting. The luminaire operates with a color temperature of 4000K (optional 3000K) and a CRI ≥ 70, offering a luminous output ratio of 100% downward with no upward emissions. Rated for IP66 protection and insulation class II, it can operate between -40°C and +50°C. Mounting options include post-top configurations for round and rectangular poles and brackets for pole diameters ranging from 102 mm to 127 mm. LED modules are removable and replaceable, and the gear tray can also be removed for maintenance. Optional control systems include fixed power, automatic dimming, custom dimming profiles, constant light flux, wireless communication, and DALI digital interface.
The MOD 2.0 URBAN 250 version offers a slightly larger profile, measuring 250×100 mm, with lengths of 500 mm and 800 mm. This version supports the same optical options as the 200 model, with identical photometric performance, color temperature, and CRI. The weight of this version reaches a maximum of 15 kg, and the exposed surface measures 0.095 m² on the side and 0.24 m² on the top. It shares similar mounting, operating, and control system options as the 200 model, ensuring consistency across different urban installation needs.
Both MOD 2.0 URBAN versions feature robust construction with die-cast aluminum fixings and extruded aluminum heat sinks, all powder painted for durability. The optics are crafted from 99.85% aluminum with a vacuum-sealed finish of 99.95%, class A+ aluminum according to DIN EN 16268. The luminaires include flat tempered glass screens of 5 mm thickness with high transparency and a polyurethane gasket for effective sealing. Cable glands are made of IP68-rated plastic, ensuring protection against environmental exposure. The combination of these materials and design features ensures long-term reliability, visual consistency, and adaptability to modern urban lighting projects.
