The RedBaron Series Anti-Collision LED Light is a high-performance lighting solution specifically engineered to meet the rigorous demands of certified aircraft applications. Utilizing state-of-the-art optical design and advanced LED array technology, the RedBaron light delivers exceptional 360-degree coverage and visibility, ensuring enhanced safety during flight. Whether configured in red or white LED variants—or custom ordered in NVIS/IR—the light offers brilliant output aided by highly polished reflectors that optimize beam distribution and intensity.
Engineered for maximum reliability, this anti-collision light is fully TSO certified, underscoring its compliance with strict aviation standards. Its robust design includes a solid anodized aluminum housing and a compact footprint measuring 64 mm by 64 mm with a depth of just under 40 mm (2.52 x 2.52 x 1.565 inches). Weighing only 145 grams (0.32 lb), the unit supports a wide operating voltage range of 9 to 36 VDC.
The light boasts powerful strobe capabilities with high input current and power ratings—up to 4.22A and 59.10W at 14V for the white strobe, and up to 2.8A and 78.53W at 28V. It flashes at a repetition rate of 50 cycles per minute, providing high visibility without the need for bulky external power supplies. Built-in protection systems ensure safe and reliable operation in all conditions, including reverse polarity protection, transient voltage protection up to 60V, and both under-voltage (lockout at 9V) and over-voltage protection (lockout at 36V). Overheat protection activates at +85°C (+185°F), further extending operational safety.
Designed to endure the harshest environments, the RedBaron light is waterproof, dust-proof, shock-proof, and vibration-proof, performing consistently across a wide ambient temperature range from -55°C to +85°C (-55°F to +185°F). This makes it an ideal solution for both fixed-wing and rotary aircraft, as well as a dependable upgrade or replacement for legacy anti-collision systems requiring top-tier performance and environmental resilience.
