Are you looking for a compact, lightweight lighting fixture that delivers high impact and sets your production apart? The SVB1™ is the answer. This striking effect, beam, and wash luminaire offers an exciting combination of output, speed, and flexibility that redefines what’s possible in a small form factor. Drawing on the robust performance legacy of the SVOPATT™ series, the SVB1™ is designed to captivate audiences with its extreme agility and powerful output, featuring continuous pan and tilt rotation for dynamic, immersive lighting effects.
At its core, the SVB1™ houses seven individually controllable 40W RGBW LED cells surrounding a central pixel, which combines RGBW capabilities with a robust 200W white strobe LED module. This combination provides full pixel-mapping capabilities and an impressive output of 11,000 lumens, offering endless creative potential for designers. The fixture’s high-efficiency optical system includes Robe’s proprietary RLCT™ lens coating, which safeguards against scratches and prevents dirt and dust buildup, significantly reducing maintenance and preserving optical clarity over time.
Its motorized zoom spans from a sharp 3.8° beam to a wide 50° wash, allowing designers to shift effortlessly between narrow and expansive coverage. This versatility is further amplified by ultra-fast movement and seamless 360° continuous pan and tilt, all delivered with remarkable quietness—perfect for high-demand environments like live productions, tours, and installations. Colour control is also robust, offering both RGB and CMY mixing modes, a wide variable CCT range from 1,700K to 20,000K, and tungsten lamp emulation with thermal delay for a truly authentic incandescent look. Additionally, the DataSwatch™ library features 66 pre-programmed colours and tones, including popular white points.
One of the standout features is ScreenPix™, an intuitive macro system that transforms each fixture’s display screen into a twelve-sector RGB colour effect zone. This functionality unlocks a visually stunning layer of depth, offering designers vibrant and animated surface effects without additional gear. With this kind of built-in creative freedom, the SVB1™ brings an extra dimension to any lighting design.
Optimized for both performance and discretion, the SVB1™ runs at just 18 dB(A) in quiet mode thanks to advanced cooling systems and a noise-dampening build. For broadcast applications, Cpulse™ flicker-free technology ensures clean, stable performance even with high-end cameras—supporting HD, UHD, and up to 16K resolution. Green correction functionality is included for fine-tuning colour accuracy in-camera.
Control is seamless and highly flexible, offering full support for protocols such as DMX-512, RDM, ArtNet, sACN, and MA Net, along with Robe’s REAP™ (Ethernet Access Portal) for simplified network management. The optional Epass™ Ethernet pass-through switch maintains network integrity even when the fixture is powered down, ensuring uninterrupted communication in mission-critical environments.
Despite its broad capabilities, the SVB1™ remains highly portable, weighing just 7.2 kg. Its rugged construction, intuitive control system, and class-leading features make it an ideal solution for lighting professionals looking to maximize impact without compromising on speed, colour precision, or reliability.
