The raw, minimalist design of this spotlight system is engineered for maximum functionality and visual impact, offering superior lighting performance with a rugged aesthetic that suits contemporary interior environments. This flexible system allows designers to optimize both light levels and color saturation for a wide variety of applications by configuring up to six spotlights within a single unit. Each module is available with medium or wide beam angles, two LED power options, and a choice of either 80 or 90 CRI to meet the specific lighting and color rendering needs of a space.
Housings are constructed of steel and designed for new construction applications. They are non I.C. rated and not suitable for use in insulated ceilings (North America only). The spotlight arrays themselves are housed in die-cast aluminum, ensuring durability and excellent thermal performance. The fully articulating gimbal mechanism offers smooth adjustability on two axes, enabling precise aiming and orientation of each spotlight.
Trim choices include standard removable flanges with a width of 19mm (0.75 inches) in White, Black, or Silver finishes, or a trimless option for seamless architectural integration. The trimless version includes mesh plates that allow drywall or plaster to be finished cleanly to the edge of the fixture. Both trim and trimless variants are suitable for ceiling thicknesses ranging from 12mm (0.5 inches) to 31mm (1.25 inches).
An optional integral emergency system (North America only) provides 1.5 hours of emergency lighting and includes a self-contained inverter module, NiCad batteries, LED charge indicator, and test switch. Electrical access is designed for maximum convenience, with no need for ceiling access and driver serviceability from below. The system supports through-branch wiring for streamlined installation.
Mounting hardware includes butterfly brackets, C-channel supports, T-bar fasteners, bar hangers, and designated suspension points for secure attachment in a variety of ceiling types. High-performance reflectors feature a vacuum-plated, highly reflective specular finish to maximize output and control glare. For 26W LED fixtures, a clear glass protective lens is included for added durability.
This fixture utilizes high-power factor (HPF) electronic drivers compatible with 120-277V (EU 240V), offering smooth 0-10V dimming down to 10%. All finishes are powder-coated to specification. The system delivers lumen output and efficacy based on a 3000K CCT and a minimum CRI of 80, with actual performance verified through LM79 photometric testing procedures. It is damp location rated and has a reported L70 lifetime exceeding 60,000 hours at 25°C (77°F). Sensor compatibility is available upon consultation with the manufacturer.
