The ProPoint Wall Washer series is a high-performance family of AC line-powered, high-brightness luminaires designed for architectural wall washing applications. Offering robust DMX512 control and built-in Remote Device Management (RDM), each fixture enables extensive configuration, monitoring, and troubleshooting capabilities. The system is engineered for simplicity and scalability with a daisy chain topology that supports up to 32 fixtures per DMX link without the need for external data injectors. Designed with flexibility in mind, ProPoint Wall Washers are compatible with e:cue and third-party control systems, and they feature a range of mounting options to suit various project needs.
The ProPoint portfolio includes RGBW, Dynamic White (DW), and Static White (SW) variants. The RGBW version combines red, green, blue, and a neutral 4000K white channel, and is offered with four beam angle options. The Dynamic White models allow smooth tuning between 2200K and 6500K, while the Static White options come in 3000K and 4000K CCTs with three beam angles. Each luminaire includes five output configurations to meet diverse lighting requirements. ProPoint fixtures are constructed with durable die-cast aluminum housings, tempered glass lenses, and are rated IP66 for outdoor and coastal environments, with certifications including ETL, FCC, RoHS, ASTM B117-16, and ANSI 3G. All models offer forward and backward tilt adjustability, operate across wide ambient temperatures from -30°C to +50°C, and feature integrated power supplies.
The ProPoint SW 20W model is a compact wall washer equipped with 12 LEDs and available in 3000K and 4000K. It delivers luminous flux of 1240 lm (3000K) and 1340 lm (4000K), achieving efficacy of up to 67 lm/W. Measuring 161mm x 130mm x 197mm and weighing 2.0 kg, this fixture includes 15°, 25°, and 35° beam angles, a 10mm (.39") thick glass lens, and a robust aluminum housing. It features 50° forward and 80° backward tilt adjustability.
The ProPoint SW 40W model features 20 LEDs and provides outputs of 2540 lm (3000K) and 2670 lm (4000K), with efficacy ratings of 63 lm/W and 66 lm/W, respectively. With dimensions of 222mm x 165mm x 254mm and a weight of 3.8 kg, it also includes three beam angle choices and a 10mm glass cover. It shares the same rugged construction and thermal tolerance as the rest of the series.
The ProPoint SW 80W model increases output significantly, using 36 LEDs to deliver up to 6075 lm at 4000K with a maximum efficacy of 75 lm/W. Measuring 257mm x 220mm x 330mm and weighing 7.6 kg, this version features a slightly thinner 8mm (.31") lens and the same beam angle and tilt options. The robust build maintains high durability in demanding environments with an IK09 impact rating.
At a higher output tier, the ProPoint SW 120W utilizes 48 LEDs to produce 8650 lm (3000K) and 9200 lm (4000K), reaching up to 76 lm/W. This model measures 315mm x 288mm x 433mm and weighs 14 kg. It is designed for large-scale illumination needs and shares the rugged IP66, coastal-rated build, and control system compatibility of the rest of the series.
The ProPoint SW 180W is the most powerful in the series, delivering up to 13,380 lm (4000K) and 12,375 lm (3000K) with efficacy up to 74 lm/W. Equipped with 60 LEDs, it matches the 120W model in size and construction (315mm x 288mm x 433mm, 14.2 kg), making it ideal for the most demanding architectural lighting applications. Like all models, it operates on 120–277V AC with a power factor ≥ 0.9 and includes integrated DMX/RDM control and power supplies for streamlined installation.
