By day, the Kubus luminaire blends into its architectural surroundings with quiet elegance, appearing as a subtle element on the wall. However, at night, it reveals its true character—delivering refined, expressive illumination. Kubus is designed with versatility in mind; thanks to dedicated accessories, it can be mounted either in or on the wall. Its ability to enhance vertical surfaces with soft grazing light transforms façades into visually dynamic compositions. Whether used for accenting architecture or guiding pedestrians, Kubus luminaires offer both aesthetic enhancement and functional clarity.
Kubus serves as both a façade luminaire and a floor washlight, enabling designers to create cohesive lighting concepts for indoor and outdoor environments using a unified system design. In pathway applications along traffic routes, Kubus provides excellent visual comfort and reliable orientation. Its discreet, minimal appearance conceals advanced, maintenance-free optoelectronics that perform with high efficiency and longevity. For additional flexibility, the Kubus system also includes bollard versions, making it suitable for a wide range of architectural and landscape lighting applications.
The optical performance of Kubus is highly customizable. Façade luminaires offer upward and downward beam emissions to structure large surfaces and bring out the depth and texture of architectural materials through grazing light. The use of Spherolit or sculpture lenses in these luminaires allows for precision in shaping the beam—either narrow or wide—depending on the design intent. To avoid glare from upward emission, mounting the luminaires above eye level is recommended, with luminaire spacing adjusted to align with architectural grids for optimal accentuation.
Floor washlights within the Kubus family are available with either wide or deep beam distributions, both delivering glare-free, subtle illumination. Wide distribution lenses such as the sculpture lens or Spherolit lens are ideal for pathways near façades, while deep distribution lenses including the prismatic or Spherolit types suit open areas adjacent to buildings. In both cases, the recommended mounting height is 0.8 meters. For even ground illumination, luminaire spacing can be up to twice the mounting height, while visual guidance applications can allow spacing up to ten times the height, offering flexibility in layout depending on visual and functional requirements.
Constructed with durability and visual harmony in mind, the Kubus luminaire housing is made from corrosion-resistant cast aluminum with a No-Rinse surface treatment, finished in Graphit m with a double powder coat. The design also minimizes dirt accumulation, contributing to its clean, low-maintenance appearance. Each luminaire features a high-power LED module available in warm white (3000K) or neutral white (4000K), with collimating lenses made from optical polymer to ensure sharp, controlled beam shaping. Protection rating IP65 guarantees the fixture is dust-tight and water jet-proof, making it well-suited to harsh outdoor environments.
Control options include standard switchable operation, with additional DALI dimmable versions available on request. ERCO also offers customizable variants, including LEDs in 2700K, 3000K with CRI 97, 3500K, and 4000K with CRI 92, along with over 10,000 housing colors to match any design vision. The Kubus luminaire system is thus a powerful and flexible solution for architects and lighting designers seeking to merge functionality, visual comfort, and architectural integration in one elegant package.
