The M-PJ path light blends sophisticated styling with dependable functionality, making it a compelling choice for modern outdoor lighting applications. Built with precision-engineered, die-cast A380 aluminum and corrosion-resistant stainless steel hardware, it features a robust construction that withstands harsh environmental conditions. A two-layer marine-grade anodization combined with a durable polyester TGIC powder coat finish ensures superior protection and long-term performance in outdoor settings, meeting stringent ASTM weathering standards.
This path light is equipped with high-performance integrated Cree® LEDs and is available in multiple configurations, including 1LED, 3LED, 6LED, and ZDC options. The LEDs are supported by gold-plated connectors and a proprietary intelligent onboard driver with firmware-controlled thermal regulation, extending the fixture’s rated life to 55,000 hours. With a maximum drive current of 1A, the M-PJ delivers lumen outputs ranging from 63 to 286, and maintains a CRI of 80+ across all variants. Photometric performance is verified using the LM-79 method.
Designed for 10–15 VAC/VDC input, the M-PJ requires a separately specified remote transformer. It supports both Phase and PWM dimming on standard LED models, and it is fully compatible with Luxor® control systems for advanced lighting customization. Users can choose the ZD option for precise zoning and dimming, or the ZDC version for full RGBW color control, with the ability to manage up to 250 lighting groups and fine-tune brightness levels in 1% increments. The standard model supports Luxor zoning by default.
For enhanced functionality, the fixture incorporates tamper-resistant features and MoistureBlock™ socket technology to protect internal components from water ingress. Polycarbonate color temperature lenses—offering 2700K (preinstalled), 3900K, 4500K, and 5200K—are included for versatile illumination customization. A UV-stabilized acrylic lens offers exceptional resistance to thermal stress and shock.
Electrical wiring consists of 18 AWG, 300V-rated cable with a 10-foot (3-meter) length, rated to 220°F (105°C). Each unit ships with a 30-inch (762 mm) length of ¾-inch (19 mm) conduit for straightforward installation in a downward lighting orientation only. The total fixture weight is approximately 1.0 lb (0.5 kg).
Sustainability is central to the M-PJ’s design. Manufactured in an ISO 9001:2015 certified facility, the fixture leverages recycled materials wherever possible without compromising durability, energy efficiency, or light quality. With its intelligent design and long life, the M-PJ provides lasting illumination while minimizing environmental impact.
The fixture is compliant with IEC 60598-1 and IEC 60598-2-7 standards when the “e” option is selected in the parts builder. It is backed by a 10-year limited warranty, ensuring peace of mind for specifiers and end-users alike.
