The XW-70 Grande Wall Wash from the Exa Collection brings together powerful LED performance and low-voltage simplicity in a durable, flexible design. With a robust output of up to 1,200 lumens and an ultra-wide 135° flood beam, it’s engineered to provide broad, even illumination for architectural and landscape applications. Available in two correlated color temperatures—2,700K and 3,000K—the XW-70 is suitable for both warm and neutral lighting environments. The fixture supports both up and down mounting orientations and includes the option of a ground stake or Mini J-Box (MJB), ensuring seamless integration into a variety of exterior settings.
Constructed from die-cast A380 aluminum with stainless steel hardware and a zinc/aluminum alloy knuckle, the XW-70 is built for the outdoors. It features a two-layer protective finish—sulfuric acid anodization and a TGIC polyester powder coat—tested to ASTM standards for superior resistance to weather and corrosion. A tempered glass lens protects the integrated Cree® LED module, offering high shock resistance and thermal durability. The luminaire’s LED system is supported by a potted driver and gold-plated connectors to ensure long-term reliability and resistance to corrosion. Proprietary onboard driver technology manages heat intelligently to maximize the LED’s life, which is rated up to 72,000 hours (L70).
The fixture's MoistureBlock™ Molex® connector safeguards internal components by preventing moisture ingress. Power is supplied via a 10' SPT-1W lead (international version slightly shorter), operating on 10–15V AC/DC for standard white or 11–15V AC for RGBW ZDC versions. Power consumption ranges from 18 to 21 watts depending on configuration, with a luminous efficacy of up to 67 lumens per watt. The fixture delivers a peak candela of 527 to 634 in the 135° very wide flood distribution.
Luxor® Technology compatibility is central to the XW-70’s smart lighting capabilities. The standard model supports zoning, while ZD and ZDC versions allow for advanced zoning and dimming control—or full-spectrum color tuning with up to 30,000 color choices in RGBW mode. Dimming can be controlled via Luxor or trailing-edge dimmers depending on system configuration. Adjustability is engineered with compress-and-lock functionality offering 9° increments across 220° of vertical motion, ensuring precise aiming with slip-resistant reliability.
Weighing 3.2 lbs (1.5 kg), the XW-70 includes a glare control shield with a 35° cutoff and mechanical seal, threaded with 1/2"-14 NPSM for standard mounting compatibility. The fixture complies with IEC 60598-1 and 60598-2-4 standards when selecting the "e" version and is rated IP66/IP67 for protection against dust and water ingress. Designed and manufactured in an ISO 9001:2015 certified facility, it’s backed by a 10-year limited warranty, reflecting its exceptional quality and sustainability focus, including the use of recycled materials where possible.
Whether used to highlight architectural façades, illuminate pathways, or wash large surfaces with ambient light, the XW-70 Grande Wall Wash offers unmatched durability, precise control, and high-performance output in a thoughtfully engineered LED solution.
