Cubic Pendant is a high-performance architectural luminaire that achieves a harmonious balance between form and function, delivering visual comfort and design elegance for small to medium-sized interior spaces. With a slim, rectangular housing just 2 1/8” deep, Cubic offers a minimalist aesthetic while delivering powerful performance. It utilizes patented SurroundLite™ indirect optics and a high-precision lightguide made of PMMA material to deliver uniform, multidimensional illumination that enhances ceilings, corners, walls, and vertical planes. This unique technology ensures soft, daylight-like brightness that minimizes glare and hot spots while creating a more natural visual environment.
The SurroundLite™ optic system is engineered with precision-coupled molecular optics, producing a three-dimensional spherical batwing light distribution. This allows light to be directed in all directions—upward, outward, and downward—resulting in balanced brightness across the entire room. The result is increased visual comfort, improved facial recognition, and reduced contrast on ceilings. Unlike traditional Lambertian optics, SurroundLite avoids direct hotspots and instead delivers softly diffused, non-Lambertian light with excellent color consistency, all while maintaining high efficacy levels up to 124 lm/W.
Designed for seamless integration into architectural layouts, Cubic Pendant supports mounting in a wide range of ceiling conditions, including slope ceiling and seismic bracing scenarios. The system is available in 2’, 4’, 8’, and 12’ segments, with continuous run capability. For runs longer than 12 feet, Cubic sections are assembled on-site using Axis' robust joining system. The modular design simplifies installation, while the toolless lens mounting and full component access from below reduce maintenance time and costs.
The fixture's advanced light distribution reduces the "cave effect" often experienced with directional lighting, while increasing perceived brightness by illuminating seams between ceilings and walls. This wide uplight spread also reduces the total number of luminaires needed to light a space, supporting efficient checkerboard layouts rather than continuous rows. Additionally, optional flat blade louvers made of electronically anodized semispecular aluminum provide added glare mitigation for enhanced occupant comfort.
Constructed with high-quality materials, Cubic features an extruded aluminum housing with die-cast aluminum end caps and joiners, and cold-rolled steel top covers. The smooth, frosted acrylic lens ensures consistent light diffusion across the entire emitting surface. Internal thermal management is handled by the aluminum housing, which acts as a heat spreader, maximizing LED lifespan and efficiency even in demanding environments rated for dry and damp locations with ambient operating temperatures from 32°F to 104°F.
Cubic is compatible with a full range of control systems. It supports Lutron EcoSystem H-Series (1%), DALI, DMX, and Xitanium SR for wireless sensors. Power-over-Ethernet (PoE) driver options are also available, and all driver configurations are UL2108 certified for integral or remote use. Emergency backup battery packs and emergency circuit configurations are optional for added resilience.
The luminaire’s lighting quality is further supported by high CRI values (80 or 90 minimum) with CCT options of 3000K, 3500K, or 4000K. Color consistency is maintained within a 3-step MacAdam ellipse across fixtures and installations. Each unit is engineered for a minimum LED lifespan of 50,000 hours at 85% lumen maintenance, meeting rigorous IES LM-80 standards.
In summary, Cubic Pendant with SurroundLite™ optics delivers more than just architectural appeal—it offers powerful and precise lighting performance tailored for modern environments where aesthetics, comfort, and efficiency must converge.
