The linear inground fixture described here is a high-output lighting solution that blends advanced technology with sleek architectural design. Engineered for performance, it features a distinctive bezel-less, edge-to-edge tempered glass slab cover and sealed tilt adjustability of ±15°, allowing for refined installation and precise lighting direction. The luminaire is built with PowerSync™ digital control, enabling fine-tuned programming through standard protocols such as DMX, RDM, Artnet, PWM, and 0–10V. Its onboard EasyGlow™ visual comfort technology minimizes glare for improved user experience, while CoolDrive™ thermal management actively regulates temperature to ensure long-term performance and durability.
Available in a variety of lengths, this fixture can be used in continuous runs and customized with flexible T and L junctions to accommodate multiple orientation configurations. The light engine options include static white, dynamic color-changing (RGBA and RGBW), and tunable white ranges, offering designers the flexibility to meet a wide range of architectural and aesthetic needs.
The fixture delivers robust photometric performance, with static white outputs ranging from 6,830 to 8,180 lumens depending on color temperature, and peak intensities up to 344,200 candela. The tunable white engine spans 2,700 K to 6,500 K with a lumen output of 7,340 and a peak intensity of 305,600 cd. For dynamic color applications, the RGBA version produces 4,490 lumens with a peak intensity of 152,800 cd. Beam angles range from narrow to wide, including elliptical optics, ensuring precise beam control for any project.
Engineered for longevity and reliability, the luminaire features marine-grade extruded aluminum housing, a marine-grade epoxy undercoat with a polyester topcoat, and a tempered glass lens, making it suitable for dry, damp, and wet locations. While not rated for underwater use, the product meets IP66 and IP67 standards and has passed IP68 tests, ensuring superior ingress protection. With an IK9 impact rating and a rated lifetime of over 60,000 hours (B10, L70, TM21), it is well-suited for high-traffic environments.
Power consumption is offered in two configurations—19 W/ft and 22 W/ft—depending on the power density selected (12 W/ft or 16 W/ft LED power), with support for both international (220–240 Vac, 50 Hz) and North American (120/277 Vac, 60 Hz) electrical systems. The fixture supports flicker-free dimming to 0.1% at a 2 kHz PWM frequency and includes advanced RDM functionality out of the box, with customizable dimming behaviors via DMX.
Weighing 14.8 lbs (6.7 kg) for a 4-foot section, and capable of operating in ambient temperatures from -40 °F to 122 °F (-40 °C to 50 °C), this fixture is a durable, high-performance choice for architectural façade, landscape, pathway, and public space lighting.
