The SuperNova DV NXT is a compact, high-powered anti-collision LED light designed for aviation applications requiring white, red, or green illumination. Engineered to be lightweight and aerodynamic, this light delivers low drag and minimal power consumption, meeting the stringent demands of modern aircraft lighting standards. Its versatile LED color options allow operators to select the appropriate signal color to suit various regulatory and operational needs.
Measuring 40 mm by 40 mm by 19.8 mm (1.575 by 1.575 by 0.78 inches) and weighing only 30 grams (1.06 ounces), the SuperNova DV NXT is ideal for integration into tight spaces where weight and size are critical. It operates within a broad voltage range of 9 to 36 volts DC, accommodating a variety of aircraft power systems. The unit’s peak input current varies by color, with white and green LEDs drawing 0.75 amps at 14 volts and 0.45 amps at 28 volts, while the red LED version draws slightly more current, 0.85 amps at 14 volts and 0.50 amps at 28 volts.
In terms of power consumption, the white and green LED models peak at 10.5 watts at 14 volts and 12.6 watts at 28 volts, whereas the red LED model peaks at 11.9 watts at 14 volts and 14 watts at 28 volts. The light features a consistent strobe repetition rate of 50 cycles per minute, providing a reliable and highly visible anti-collision signal. The SuperNova DV NXT is designed to operate in extreme ambient temperatures ranging from -55°C to +85°C (-67°F to +185°F), making it suitable for a wide range of environmental conditions.
Safety and durability are paramount in the design of the SuperNova DV NXT. It incorporates overheat protection that activates at 85°C (185°F), reverse polarity protection to prevent damage from incorrect wiring, and transient voltage tolerance up to 39 volts. Additionally, the unit features under-voltage lockout to protect against insufficient power conditions. Built to endure demanding aviation environments, the SuperNova DV NXT is fully waterproof, dust-proof, and vibration-proof, ensuring reliable performance and longevity in the field.
