The Leaf series LED street lights, launched by ZGSM in 2023, introduce a modern and versatile solution for urban street lighting. With a sleek casing, contemporary design, and tool-free opening, these luminaires are built for both aesthetic integration and practical functionality in city environments. The series was named “Leaf” to reflect its vision of harmonizing with urban infrastructure, akin to leaves lining roads or pedestrian pathways, providing consistent and reliable lighting while enhancing the visual appeal of streets and public areas.
The Leaf series emphasizes environmentally conscious lighting and efficiency, symbolizing “green lighting” in urban projects. Its cost-effectiveness stems from high luminous efficacy paired with a competitive price per watt. The luminaires support scheduled dimming with customizable profiles set at the factory, which allows precise adjustment of light levels over time and contributes to significant energy management. Maintenance and upgrades are straightforward due to the tool-free opening and compatibility with NEMA sockets, enabling easy installation of smart controls or future system enhancements. Additionally, the Leaf series offers a long operational lifespan of over 100,000 hours for L70, ensuring sustained brightness and low decay over many years.
Performance is driven by high-quality Lumileds LEDs, achieving luminaire efficacy of up to 199 lm/W. The luminaires include built-in 10kV surge protection, with an optional 20kV upgrade available, offering protection against electrical fluctuations. With IP66 ingress protection and IK09 impact resistance, the Leaf series maintains reliable performance under harsh weather and mechanical stresses. Operating voltage ranges from 100–240/277 VAC with a power factor above 0.95, while color temperature options span from 2200K to 6500K and CRI values of Ra>70 or Ra>80, providing comfortable and consistent visual conditions for urban streets and public spaces.
Optical versatility is provided through two available light distributions, accommodating different street layouts and urban lighting needs. The series also supports a wide range of smart control options, including daylight sensors, DALI dimming, 1–10V dimming, motion sensors, Zigbee, LoRa, and NEMA or Zhaga sockets, allowing integration with intelligent control systems for adaptive operation and future-proofed infrastructure. Mounting flexibility includes side-entry or vertical pole configurations using optional adapters, making the luminaires suitable for diverse installation scenarios.
Certified to meet international standards, the Leaf series carries CE, RoHS, ENEC, CB, Zhaga-D4i, LM79, LM80, TM-21, IEC62471/62778, IEC60068-2-6, IEC61643-11, ISO9227, and CISPR15:2018 approvals, ensuring professional-grade safety, quality, and reliability. With a five-year warranty and robust design, the Leaf series represents a sustainable, practical, and visually appealing solution for modern urban street lighting, combining long lifespan, intelligent control capabilities, and flexible installation options.
