The RGBA 4-in-1 PixelControl LED strip light is an advanced lighting solution designed to expand creative color mixing possibilities by combining amber with traditional RGB nodes. Unlike standard RGB strips, this fixture incorporates red, green, blue, and amber into a single LED package, producing richer and more nuanced tones that standard configurations cannot achieve. With one RGBA 4-in-1 LED per pixel, the strip allows designers to seamlessly blend RGB with amber on a pixel-by-pixel basis, unlocking smooth gradients, stunning fades, and vibrant dynamic effects. Each two-meter reel includes 120 individually addressable pixels, with a density of 60 high-quality RGBA LEDs per meter and a compact 10mm width. Its smallest cutting increment, cuttable at every LED, makes it exceptionally versatile for precision installations.
This LED strip is engineered for compatibility with a range of PixelControl LED controllers, which eliminate the need for separate DMX decoders in standalone use. These controllers enable precise control of speed, brightness, direction, and a full spectrum of pre-programmed or custom chasing and color-changing effects. For integration into larger professional setups, the RGBA 4-in-1 PixelControl can easily be paired with the DMX512 V2 PixelControl Decoder, which translates standard DMX512 output into the required data signal for seamless communication. This makes the strip equally suitable for standalone creative projects and sophisticated DMX-controlled lighting systems.
Each reel of the RGBA 4-in-1 PixelControl strip is fitted with a female SM connector on the input side and a male SM connector with a built-in power injector on the output side. For reliable performance in extended installations, additional power should be injected approximately every 120 LEDs to prevent voltage drop and maintain brightness consistency. The strip is directional, with arrows clearly marked to indicate the correct input orientation. When using SM connectors, the maximum recommended amperage is 3.5A per connector to ensure safe and stable operation.
Technical specifications further highlight the strip’s capabilities. Each pixel is addressable in the order of Green-Red-Blue-Amber, driven by a WS2814 IC and operating on 5 VDC. Each reel contains 120 pixels, equivalent to approximately 0.93 universes of DMX data. Power consumption is 25.5 watts per reel, or about 12.8 watts per meter, with an input current of 5100 mA. The strip is cuttable every 0.65 inches (16.7 mm), providing excellent adaptability to fit precise project needs. The 5050 LED node size delivers a light output across red, green, blue, and amber wavelengths of 623 nm, 522 nm, 472 nm, and 592 nm respectively.
The RGBA 4-in-1 PixelControl LED strip light is an outstanding choice for installations that demand dynamic animated effects and enhanced color quality beyond standard RGB. Whether used for architectural lighting, entertainment venues, stage productions, or creative displays, it empowers lighting designers to craft custom animations, immersive effects, and dramatic color transitions with remarkable precision and flexibility.
