The RGB PixelPro LED Bullets are a powerful and versatile pixel lighting solution designed to deliver high-impact animated effects with exceptional precision. Each bullet integrates an 8mm diffused RGB LED paired with an intelligent WS2801 integrated circuit chip, ensuring smooth performance, superior efficiency, and an expansive color range. Unlike traditional lighting, every individual LED can be controlled independently, allowing designers to craft intricate effects such as chasing, waves, fades, and vibrant full-color patterns across large installations. With one IC chip per module requiring three addresses for full RGB control, PixelPro offers unparalleled flexibility in dynamic lighting design. The silicon-molded package ensures durability, consistent diffusion, and a compact form factor that enhances both indoor and outdoor applications.
Designed for ease of integration, the PixelPro LED Bullets work seamlessly with the DMX512 Pixel Decoder (DMX512-PX-2801), which translates standard DMX output into the WS2801 serial protocol, enabling compatibility with a wide range of DMX controllers and lighting consoles. This setup makes it easy to customize and control each LED in real time, delivering precise, professional-grade effects. The pixel-level control opens up virtually unlimited creative possibilities, from immersive stage productions to interactive displays and architectural installations, making PixelPro an indispensable tool for designers seeking advanced lighting flexibility.
Each string of PixelPro Bullets is preassembled with 50 modules, featuring input and output connectors for simple linking. The system is directional, with the female connector serving as the input and the male connector as the output, and orientation is clearly marked with arrows. The modules are housed in IP65-rated silicon enclosures for water resistance, although cutting the string or connectors will compromise waterproofing. Installation is straightforward, thanks to 0.6 mm notches designed to punch through boards, allowing secure sheet-mounting in 12mm holes. With 10 cm of flexible wiring between modules, users can easily adjust spacing, reposition bullets to eliminate dark spots, and customize layouts with simple cut-and-splice methods.
The PixelPro Bullets are engineered for reliability and long-term use, supporting 5 VDC input only (12 VDC will damage the ICs). Each LED consumes 0.3 watts, with a full 50-module string drawing approximately 15 watts. Recommended power injection at every string helps reduce voltage drop and ensures consistent brightness throughout long runs. Additional power can be applied at both ends or mid-run using power injector plugs. The LEDs offer a 120° beam angle, vibrant RGB output at 623nm (red), 522nm (green), and 472nm (blue), and a rated lifetime of 50,000 hours. Constructed with premium LED components, PixelPro delivers maximum brightness, rich color rendering, and longevity, while emitting no harmful UV radiation, making it safe for artwork and sensitive displays.
Measuring 12.7 mm wide and 36.8 mm tall per module, these compact, high-quality lights are RoHS-compliant and backed by a three-year limited warranty. PixelPro connectors are available as companion parts for simplified setup, and detailed installation instructions and technical support are provided to ensure project success. With their combination of rugged design, precision control, and unmatched creative potential, the RGB PixelPro LED Bullets stand out as a professional-grade solution for designers, architects, and lighting professionals seeking to push the boundaries of pixel-based illumination.
