The SafeSite® LED Area Light is a high-performance industrial fixture designed to deliver dependable illumination and safety in hazardous and harsh environments. Engineered for critical operations, it offers integrated battery backup that provides emergency lighting for a minimum of 90 minutes in the event of a power disruption. This added layer of reliability ensures continued visibility and enhanced protection for personnel working in high-risk settings.
Constructed with durability and versatility in mind, the SafeSite LED Area Light features a rugged copper-free aluminum housing with a superior dual-coat finish—comprising an epoxy primer and sealed polyester topcoat—for long-lasting protection against corrosion and environmental degradation. The fixture meets stringent industrial requirements with certifications including UL 844 (CID2, CIID1, CIID2, CIII), UL 1598/A, UL 924, and CSA. Rated IP66 and NEMA 4X, it is well-suited for use in demanding environments with exposure to moisture, dust, and other contaminants.
Offering lumen packages from 2,800 to 9,000 lumens with up to 128 lumens per watt efficacy, this luminaire combines energy efficiency with high-output performance. It supports three optical distributions: 360°, 180° forward throw for 45° mounting, and wide beam for 0° mounting applications. Users can choose between cool white (5000K), neutral white (4000K), and warm white (2700K) correlated color temperatures, all with a high color rendering index (CRI) of 80 for accurate visual recognition.
The lens options include either a hard-coated polycarbonate lens rated IK10 for superior impact resistance or a tempered glass lens rated IK07 for added durability. Electrical specifications include a wide operating voltage range of 100–277 VAC (50/60 Hz) and 120–250 VDC. The fixture operates in extreme temperatures from -40°F to +149°F (-40°C to +65°C) and offers a power factor greater than 0.9 with total harmonic distortion (THD) under 20%. It also features robust EMC performance, compliant with FCC Title 47, Subpart B, Section 15, Class A, and RF immunity up to 20V/m from 80 MHz to 1 GHz, along with 6 kV transient protection.
Installation is streamlined with flexible mounting options including ceiling, wall, and UMA configurations. It comes equipped with a 10-foot STOOW cable (1.02 mm, 18 AWG) for simplified wiring. Designed to be both functional and aesthetically streamlined, the SafeSite LED Area Light is finished in grey (RAL 7040) and backed by Dialight’s 10-year warranty, ensuring long-term performance, minimal maintenance, and total peace of mind in mission-critical applications.
