The NOVA cuboid LED pendant light is designed to deliver powerful performance within a compact architectural form. With shell heights ranging from 2.5 to 6 inches and aperture sizes of 2.5, 3.5, and 6 inches, it offers a balance of minimal scale and high-output capability. Despite its small footprint, the luminaire achieves lumen packages up to 3,000 lumens while maintaining excellent optical precision. Its advanced distribution system includes beam angles from 10° to 90°, as well as specialized ovular and wall wash lenses, making it a versatile option for accent, task, or general illumination. The optional NOVA glow feature enhances the fixture’s square cylinder profile with an ambient, decorative effect, adding depth and visual interest to its performance-driven design.
Engineered for flexibility in application, NOVA provides direct illumination and can be installed in multiple mounting configurations, including pendant suspension, surface mount, wall sconce, or yoke mount. Its output range of 500 to 3,000 lumens is supported by power consumption between 3.7 and 25.2 watts, achieving efficacies up to 129 lumens per watt. The fixture is available in four standard color temperatures—2700K, 3000K, 3500K, and 4000K—with 90 CRI and 3-step MacAdam ellipse color consistency, ensuring high-quality, uniform light across installations.
A wide selection of reflector options allows NOVA to adapt to diverse lighting needs. Beam shaping includes distributions from narrow spot to wide flood, as well as wall wash and square optics. Both reflectors and lenses are field replaceable without tools, enabling easy reconfiguration in the field. Glow optics are also available, offering either reflector-based or diffuse lens treatments for enhanced visual comfort and design flexibility. Driver options include internal, deep canopy, or remote configurations, supporting multiple dimming protocols such as 0-10V, Phase, DALI, DMX, eldoLED, and Lutron, with dimming to 0% available in select models.
Constructed from extruded aluminum with galvanized steel hardware, the NOVA cuboid LED pendant light ensures durability while maintaining a refined architectural appearance. It is UL listed for dry and damp locations, weighs up to 3.8 pounds, and is offered in up to 17 standard finishes, with custom colors and special-order options available. The NOVA 6 variant includes conduit cutouts for added installation flexibility. Certified to UL and CSA standards, the fixture combines compact design, powerful light output, and extensive customization to meet the needs of commercial, residential, and architectural lighting environments.
