The Axcor Spot 400 is a compact and powerful LED moving spotlight designed for medium-power applications, offering an exceptional combination of features for diverse visual effects. Its high-efficiency 300W white LED module produces a remarkably bright output, providing a light source with a CRI of at least 70 at 6500K (Axcor Spot 400) or at least 90 at 5600K (Axcor Spot 400 HC), ensuring vibrant and accurate color reproduction. The fixture boasts a variety of advanced tools for lighting designers, including two rotating dichroic glass gobo wheels with a total of 14 rotating gobos, an animation disc, a rotating prism, a power-driven iris, and a 16-bit dimmer. These features enable the creation of dynamic and intricate lighting effects, making the Axcor Spot 400 ideal for a wide range of applications.
One of the standout features of the Axcor Spot 400 is its remarkable zoom range, which spans from 5.4° to 57.3°, offering a 1:10 zoom ratio. This flexibility allows for precise control over beam aperture and light distribution, making it versatile enough for both narrow, focused beams and wide, soft washes. The fixture also incorporates a highly efficient optical system with a 125mm front lens, ensuring uniform light output across the zoom range. Additionally, its color system is based on a CMY mixing system, complemented by a linear CTO and a 6-color wheel, providing smooth color transitions and a broad spectrum of hues for creative lighting effects.
The Axcor Spot 400 is equipped with a variety of dynamic effects, including variable frost (0-100%) and a rotating 4-facet prism with 540° of rotation in both clockwise and counterclockwise directions at variable speeds. The fixture also features an animation wheel, multiple macros on the iris (such as random and pulsing effects), and an electronic dimmer with four selectable dimming curves. For strobing effects, the Axcor Spot 400 offers an electronic strobe at 25 flashes per second with instant open and blackout capabilities, adding to its ability to create fast, intense lighting moments.
In terms of control and connectivity, the Axcor Spot 400 supports a variety of protocols, including DMX, Art-Net, RDM, and sACN, with 28 control channels in single mode. It features locking 5-pin XLR connectors for DMX and RDM, as well as an RJ45 Ethernet port for network control. The fixture also includes a PowerCon True1 IN/OUT connector, offering reliable power connections for flexible setup options. Additionally, the built-in web server enables remote access for firmware upgrades, diagnostics, and DMX monitoring, while CloudIO compatibility provides further versatility in advanced control systems.
Designed for durability and ease of transport, the Axcor Spot 400 features an aluminum and steel housing with plastic covers. It is equipped with two side handles and has an IP20 protection rating, making it suitable for various environments. The fixture operates in any position and includes a fast-lock omega clamp for quick mounting, along with an optional safety chain for added security. With a self-charging battery, graphic LCD display, and the ability to upload firmware from another fixture, the Axcor Spot 400 is a reliable and user-friendly solution for professionals.
The Axcor Spot 400 operates on an electronic auto-range power supply with active PFC, ensuring efficient energy use across a range of voltages (100-240V, 50/60 Hz). With a maximum power consumption of 540VA, it is designed for energy efficiency without sacrificing performance. Additionally, the fixture is thermally protected with a fuse and forced ventilation to ensure safe operation, even in demanding conditions.
The Axcor Spot 400 is built with safety in mind, featuring thermal protection, forced ventilation, and a low-noise operation. In Auto Fan Mode, the fixture operates at 46.5 dBA, while the Theatre/Silent Fan Mode reduces noise to 40.0 dBA, making it suitable for performance environments where noise control is critical. With its high output, dynamic features, and flexible control options, the Axcor Spot 400 is a top-tier choice for lighting designers seeking powerful and versatile spotlights for stage, event, and architectural lighting.
