Step into a new era of lighting with the Actoris Fresnel from ADB by Claypaky, a next-generation LED Fresnel spotlight purpose-built for professional broadcast, film, and theatre applications. This fixture expands Claypaky’s Multispectral range with a bold leap in color precision, luminous performance, and operational flexibility. Whether you're crafting dramatic stage washes or studio-ready key lights, Actoris Fresnel offers breathtaking results with velvet-smooth color transitions and unrivaled fidelity.
At the heart of Actoris Fresnel is a powerful 6-color RGBAL + Royal Blue LED engine, delivering up to 370 watts of output and reaching a Color Rendering Index (CRI) as high as 97. This advanced color system provides a wide color gamut and extended spectral response, faithfully reproducing both bold colors and subtle tonal transitions. Its dynamic white capabilities allow color temperature tuning from 2500K to 10,000K, with precise Plankcurve accuracy and ± green/magenta tint correction, ensuring clean, consistent white light across a range of settings. A tungsten emulation mode replicates the familiar warmth and color shift of traditional incandescent sources during dimming.
The optical performance is equally impressive. Actoris Fresnel is equipped with a high-quality Fresnel lens and a 10°–60° motorized zoom, allowing seamless transitions from narrow spot to wide-area floodlight. This soft-edged beam delivers the hallmark smooth wash expected of Fresnel luminaires, while its consistent output—up to 17,700 lumens—makes it ideal for demanding stage or studio environments.
Engineered with professional workflows in mind, Actoris Fresnel includes numerous features that streamline both setup and operation. The Pointing Mode makes beam alignment quick and precise, while Standalone Mode allows users to store and recall looks directly from the fixture without a console. It also integrates with advanced lighting networks using DMX, Art-Net, RDM, and sACN protocols, and includes a built-in web server for remote configuration and diagnostics. CloudIO compatibility enables on-field calibration to ensure long-term color consistency across fixtures.
Dimming performance is state-of-the-art, featuring 24-bit resolution with five selectable dimming curves, resulting in ultra-smooth fades with no visible flicker—ideal for camera applications. The fixture supports multiple color control modes (Advanced, Standard, White, Single-channel), flicker-free operation via PWM frequency adjustment, and includes red shift and electronic strobe effects up to 25 fps.
Constructed with a lightweight aluminum housing and a sliding stirrup for perfect balance, the Actoris Fresnel is both robust and easy to rig. It includes PowerCON True1 connectors, locking 5-pin XLR and RJ45 Ethernet ports, and an IP20 rating for indoor use in any orientation. Designed for reliability in professional environments, it operates in ambient temperatures ranging from -20°C to 45°C and consumes up to 530 watts of power.
From rich color performance to whisper-silent operation and intelligent control, Actoris Fresnel redefines what a professional-grade Fresnel fixture can achieve. Contact us today to learn how this powerful addition can transform your lighting rig.
