The ZG-900 post top light preserves the classic appearance and style of traditional street lamps while incorporating modern LED technology to meet contemporary outdoor lighting needs. The ZGSM variant enhances system efficiency, lens performance, and heat dissipation, making the series highly suitable for applications such as parking lots, pedestrian streets, parks, and residential roads. Equipped with multiple lens options, the luminaire ensures optimal light distribution tailored to specific site requirements, delivering consistent and uniform coverage for both roadways and public spaces.
This series achieves high luminaire efficacy of up to 150 lumens per watt, combining quality LEDs with an efficient thermal management system to maintain stable performance. The die-cast aluminum housing (ADC12) provides durability, while the integrated heat dissipation design maximizes thermal transfer, extending lamp life and reducing maintenance frequency. With a rated life of over 100,000 hours, equivalent to more than 20 years of operation at 12 hours per day, these luminaires provide long-term reliability and lower total operating costs.
The ZG-900/ZGSM series supports a wide range of power options, including 40W, 60W, 80W, and 100W, and offers both Class I and Class II electrical configurations to suit different installation requirements. It carries IP66 and IK08 ratings for protection against water, dust, and mechanical impact, ensuring safe operation in outdoor environments. The optical system provides various symmetrical and asymmetrical light distributions, including Type I, II, III, V, or customized options, for targeted and even lighting.
Maintenance is simplified with easily removable drivers and surge protection devices (SPD), allowing quick replacement when necessary. The series also includes 1–10V dimming (default) and timer dimming options, supporting flexible control of light output. Standard surge protection is rated at 6 kV differential mode and 10 kV common mode, with higher surge protection available upon request. Additional technical specifications include input voltage of 100–240/277 VAC at 50/60 Hz, a power factor exceeding 0.95, and post top mounting. The ZG-900/ZGSM luminaires come with a five-year warranty and meet international certifications including CE, RoHS, IP66, IK10, LM80, TM-21, and IEC62471, ensuring compliance with global safety, performance, and durability standards.
