The plain fitter LED globe is a classic outdoor luminaire that combines timeless Art Deco styling with modern LED technology. Its design features an acrylic globe housed within a cast aluminum dish fitter, providing a clean, uniformly lit surface that enhances the aesthetic of streets, campuses, parks, and municipal spaces. Available in white, frosted, translucent red, and translucent blue, the globes come in sizes ranging from 14" to 22", creating an elegant lighting effect suitable for a wide range of urban and architectural environments. Optional vinyl lettering, including standard designs such as "Fire" or "Police" or custom text, can be applied to enhance identification or branding while maintaining a high-quality, outdoor-rated finish.
The globe fixture is engineered for durability and long-term outdoor use. Its heavy-wall cast aluminum fitter ensures high tensile strength and stability, and it includes four stainless steel Allen-head set screws for secure attachment to a pole or tenon. Depending on globe size, the fixture accommodates 3" OD tenons of varying heights—1.5" for 14" globes and 3" for 16" to 22" globes. This design allows for a clean, seamless aesthetic, particularly when used with the "Arm Mount" option, which connects the luminaire directly to compatible arms such as the 80, 78, 480, 478, 1080, 1089, 1082, and 121 models. Stainless steel hardware is included for all mounting configurations, with black oxide coatings for darker finishes and uncoated hardware for lighter finishes.
The luminaire is compatible with a variety of mounting options, including wall mount, post-top, single or multi-arm mounts, mid-mount, and pier-base applications, ensuring versatile installation for outdoor area lighting. The acrylic globes are held in place with internal wing clamps, with a 5" hole in the 14" globe and 8" holes in larger sizes, ensuring stability and uniform light distribution.
At the heart of the fixture’s performance is the LED light engine. The LEDs are mounted horizontally in an upward-facing orientation, delivering both direct illumination and subtle up-light to enhance the globe’s exterior appearance. Utilizing high-output, high-brightness Chip-on-Board (COB) LEDs, the system is 100% recyclable, free of hazardous substances such as lead and mercury, and RoHS compliant. Lumen maintenance is determined according to IESNA TM-21 standards, with in-situ testing performed by NVLAP-accredited laboratories. The LEDs provide a lifespan of up to 100,000 hours at 70% of initial output at 25°C. Color temperatures range from 2700K to 5000K, with a minimum CRI of 70, while custom CCT options are available upon request.
The light output is evenly distributed using a single molded silicone omnidirectional optic applied to each LED, providing symmetric light dispersion within the globe. This ensures a uniform, aesthetically pleasing exterior glow and eliminates hotspots or uneven illumination. Optical testing is conducted in accordance with IESNA LM-79 standards to guarantee reliable performance.
Electrical performance and flexibility are also key features. The LED driver is UL recognized and can be mounted remotely in the arm, pole, base, or integral to a pier-base configuration. It operates at 50/60Hz, supports 0–10V dimming, and includes overload, overheat, and short-circuit protection. Additionally, it is supplied with supplemental surge protection in accordance with IEEE/ANSI C62.41.2 guidelines, a high-power factor above 0.9, and total harmonic distortion below 20%, ensuring consistent and reliable operation. Optional Fixed Dimming Resistor Boards (FDRB) allow for fine field-adjustable light level control from 25% to 100% of the original output, with a durable composite enclosure designed for long-term protection.
The plain fitter LED globe is UL listed per UL1598 and CSA C22.2 No. 250.0, making it suitable for wet locations throughout the United States and Canada. Its six-stage polyester powder coat finish provides a durable, high-end surface that resists environmental wear, exceeding standards including AAMA 2604, AAMA 2605, ASTM D523, and ASTM D4214. Traditional finish options are also available, including Black, White, Park Green, Architectural Medium Bronze, and Dark Bronze, with both smooth and textured options. This attention to detail ensures the luminaire integrates seamlessly with diverse outdoor architectural and urban environments.
Finally, the plain fitter LED globe delivers a classic, timeless appearance while providing modern LED illumination suitable for a variety of outdoor area applications. Its combination of customizable optics, durable construction, versatile mounting options, and advanced LED technology makes it an ideal choice for streetscapes, campuses, parks, and municipal projects, offering both functional illumination and decorative visual appeal.
