The VO In-Grade/Wall Light is a durable and versatile fixture designed for both in-ground and recessed wall applications, making it ideal for landscape and hardscape environments. Constructed with 316 marine-grade stainless steel and a polymer housing, the VO fixture ensures long-term resilience even in concrete, subterranean, or high-moisture settings. It ships with a robust installation sleeve for easy and secure mounting. The fixture supports multiple faceplate options, offering design flexibility for various aesthetic needs.
Engineered for high performance, the VO In-Grade/Wall Light operates on an input voltage of 10–15V and is dimmable via phase or PWM control. It is fully compatible with Luxor® technology, enabling zoning and dimming (ZD) functions through the Luxor controller. This allows luminaires to be grouped into up to 250 zones, each dimmable in 1% increments from 0% to 100%. The fixture is also compatible with the Light Assignment Module (LAM) for simplified configuration.
The VO series offers several output configurations, including standard (ST), radial (RD), and two glow versions (GW180 and GW360). The ST model produces up to 178 lumens with a peak center beam candlepower of 431 and an efficacy of 64 lumens per watt. The RD version outputs 98 lumens with a narrower vertical beam angle of 20.7°, while the GW models offer subtle glow effects with lower lumen output. All models feature a 2,700K color temperature and a CRI of 80+, providing warm and consistent illumination.
Each model includes low-glare optics with a 30° beam angle and frosted lens for comfortable lighting distribution. The fixture utilizes Lumileds® LEDs and features integrated CoolDrive™ thermal management for consistent performance and longevity. With a rated life of over 60,000 hours (L70, B10, TM21 reported), the VO series provides reliable and efficient illumination for demanding exterior applications.
The fixture is IP-rated and compliant with dark-sky standards (BUG Rating: B0-U1-G1). It also meets drive-over standards, capable of withstanding static loads up to 992 lbs (450 kg). Designed with sustainability in mind, the VO light is manufactured in an ISO 9001:2015 certified facility using environmentally conscious practices and materials where possible.
Additional specifications include an ambient operating temperature range of -4°F to 122°F (-20°C to 50°C), natural stainless steel finish, and flexible rubber cable wiring. The fixture requires a remote transformer (sold separately) and includes an installation sleeve for ease of setup. For conduit installation, users can swap O-rings to fit 1.5" schedule 40 PVC conduit. The VO In-Grade/Wall Light is backed by a 10-year warranty, ensuring peace of mind and enduring performance in architectural and landscape lighting projects.
