The JMAZ ATTCO BEAM 230 is a high-output moving head beam fixture powered by a 231W OSRAM SIRIUS HRI discharge lamp, capable of producing a brilliant 164,230 lux at 10 meters. Designed for maximum impact in large-scale lighting environments, it features a focused 2.5° beam angle and a 136mm anti-reflective lens for sharp, precise beams. An electronic motorized focus system provides seamless adjustment from 2.5 to 30 meters, giving users full flexibility in various venue sizes and setups.
This fixture offers a rich set of visual effects, including an 11-color wheel plus open, 16 static gobos, and a dual-prism system—one 16-facet prism and one 8+16-facet combination prism with variable speed and direction. The addition of a frost filter allows for soft wash effects, while dual-flag mechanical dimming and a smooth 0–100% linear dimmer ensure refined output control. A total of nine built-in auto and sound-activated programs make this fixture both powerful and user-friendly right out of the box.
Control options are extensive, with 3-pin DMX512 In/Out, wireless DMX, and RF remote functionality. Two DMX personalities (14 and 16 channels) offer flexibility for integration into various lighting rigs. The unit features an intuitive 2.4" TFT LCD display, pan and tilt movement of 630° and 270° respectively, and smooth 8/16-bit movement resolution.
Housed in a durable high-temperature plastic and cast aluminum shell, the ATTCO BEAM 230 includes a cooling fan for thermal management and a quick-lock Omega bracket for fast and secure mounting. It operates within a temperature range of -35°C to 45°C, making it suitable for a wide range of environments. The fixture is equipped with powerCON In/Out and consumes a maximum of 190W. Included accessories are an RF remote, Omega bracket, powerCON cable, DMX cable, and safety attachments for immediate deployment.
